Associated Numbers
UD11196A AS-PL CAL35315GS CASCO DRA0047 DELCO A003TG1691 MITSUBISHI A3TG1691 MITSUBISHIList 20137513OE REAL 2035315 SANDO ALT32231 WOODAUTO 145554090 PSH 930047 EDR 930047N Mitsubishi Remy DRA0047N 656641 a3tg2881 a3tg2881A A3tg2881 554233RI ZJ10-18-300B ZJ10-18-300 zj1018300C ZJ1018300A zj1018300B A3TG2881 mxa2101 ANJ569
Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M10x1.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 162 mm |
| Mount Inside Length or Pad Mount C-C (C) | 67 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_2005 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 14.5 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | 2 1.3 | 01.2003- | |
| MAZDA | 2 1.5 | 01.2003- | |
| MAZDA | Demio 1.3 | 01.2003- | |
| MAZDA | Demio 1.5 | 01.2003- |
Alternatives >>>
A5255 - Remanufactured Option
A5069 - Brand new 3 Pin version ** Can use but will require ATP6001 wiring plug**
Reference Information
A3TG1691 ALT5193 A003TG1691 554233RI DRA0047 1.45554E+11 ALT32231 2035315 UD11196A CAL35315GS 20137513OE ALTF858 ANM32267XVideo/Publications
20137513OE 2035315 554233RI A003TG1691 A3TG1691 ALT32231 ALTF858 CAL35315GS DRA0047 UD11196A< Critical Notes >
For use in place of A3TG2881 A3TG2881A alternator you will be required to purchase an AFP5002 AFP5002(INA) clutch pulley.
Some times modification to the DE bracket is required if the bracket has an aluminium casting around the the shaft in order to fit the pulley on.
** If you require this and are unable to undertake this job let us know and we can complete this task for you for a small fee**
