Associated Numbers
UD10060A ASPL AEC2042 AUTOELECTRO CAL35263AS CASCO CAL35263GS EAA222249 EAA 276592 ELSTOCK CA2042IR HC PARTS 302042 KUHNER LRA03482 LUCAS ZJ3818300 MAZDA A002TG1391ZD MITSUBISHIList A2TG1391 20137362BN REAL 2035263 SANDO 11578N WAI / TRANSPO UNIT BOM 2035281 Arrowhead MAT0271 Lester 11578 Mazda Mitsubishi PIC Picture ID Remy Light Duty 11142 References: J N 40048275 0986082430 Bosch ruil 12060970 EuroTec 145557090 PSH Elstock 57403 EAI 6493SP Spidan 930639 EDR A002TG1391 ALT3060 Unipoint ALT5195sa Electrolog DRA0639 F042303122 HCA2042IR Lucas TNA057 TWA mxa2048 6566411 ANJ568 anj568GQ 27-6592 EAA-222249 203-5281 14-778Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 13.5 mm |
Diameter (D.1) | M10x1.25 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 163 mm |
Mount Inside Length or Pad Mount C-C (C) | 66 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_3310 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 16 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAZDA | 2 1.3 | [ZJ-VE] | 10.2007- |
MAZDA | 2 1.3 | [ZJ46] | 10.2007-06.2015 |
MAZDA | 2 1.3 BiFuel | [ZJ-46] | 05.2011-11.2014 |
MAZDA | 2 1.3 MZR | [ZJ-VE] | 01.2010-06.2015 |
MAZDA | 2 1.3 MZR | [ZJ46] | 01.2010-06.2015 |
MAZDA | 2 1.5 | [ZY-DE] | 10.2007- |
MAZDA | 2 1.5 | [ZY-VE] | 10.2007- |
MAZDA | 2 1.5 | [ZY-VE] | 10.2007-06.2015 |
MAZDA | 2 1.5 | [ZY66] | 07.2007-06.2015 |
MAZDA | 2 1.5 | [ZY84] | 07.2007-06.2015 |
MAZDA | 2 1.5 MZR | [ZY05] | 06.2011-06.2015 |
MAZDA | 2 1.5 MZR | [ZY66] | 06.2011-06.2015 |
MAZDA | 3 1.6 | [Z6Y1] | 09.2013-05.2019 |
MAZDA | 3 1.6 | [Z6Y3] | 09.2013-05.2019 |
MAZDA | 3 1.6 MZR | 06.2009- |
Alternatives >>>
A5255 - Brand new unit ** WITH 2 PIN PLUG**
A5255R - Remanufactured unit ** WITH 2 PIN PLUG**
USE ATP5001 Wiring plug if you want to use the above options
Reference Information
A12MH0654A2 A12MH0654 A2TG1391 ALM9131 ANM32859X 2035263 A002TG1391AM 446241 A002TG1391ZD 8EL738212681 209405 LRA03482 CAL35263GS PRAF113 CA2042 MITA2TG1391 ALT5195 AEC2042 89215217 BOM 20137362BN UNIT ALT372630 145.557.090.138 4G0649 20137362OE ZJ3818300 145.557.090.370 J5113074 145.557.090.130 203-5281 443157 11578N CA2042IR 90-27-3418 115795 A2TG13191 A002TG1391 ANM32859 UD10060A 27-6592 0986082430 CAL35263AS 57403 5535999 EAA-222249 ALT372630A 302042 DRA0639 9334 RNLA2TG1391 LRA3482 RAA11740 2035263.1 A2TG1391AM 8EL012430-681 A2TG1391ZD A5069 ALT31327 ALTF113 209405A 986082430Video/Publications
11578N 115795 20137362BN 2035263 27-6592 302042 A002TG1391ZD A2TG1391 A5069 AEC2042 ALTF113 CA2042 CA2042IR CAL35263AS CAL35263GS EAA-222249 LRA03482 LRA3482 RNLA2TG1391 UD10060A UNIT BOM 203-5281 ZJ3818300 209405< Critical Notes >
This unit is a 3 pin Plug unit, You can use this in place of the 2 pin But you will need to purchase ATP6001 wiring plug to change the plug.
Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
