Associated Numbers
0001107088 0001107433 0001107434 0986018480 0986020551 0986021060 113271 201230 201230D 201236 20513001 228000-7580 228000-7581 228000-7583 228000-7591 25-2404 25-2472 25-2504 25-3159 28100-0D030 28100-0D130 28100-22030 28100-22040 32630R 428000-7740 458485 8EA738002-001 AES2244 AEY2399 DRS3935 DRS8480 DRT1060 DSN921 JS1236 LRS01509 LRS01630 LRT00244 STR50185 28100-22100 428000-3950 4280003950 4280003951 2810022100 428000-3951 snj214 dxs4050 70-8117 2810022030
Specifications
Kilowatt | 1 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 116 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 13.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.4 | [4ZZ-FE] | 03.2007-09.2012 |
TOYOTA | Avensis 1.6 Liftback | [3ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Avensis 1.6 VVT-i | [3ZZ-FE] | 04.2003-11.2008 |
TOYOTA | Avensis 1.6 VVT-i | [3ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Avensis 1.8 | [1ZZ-FE] | 03.2003-10.2008 |
TOYOTA | Avensis 1.8 | [1ZZ-FE] | 04.2003-11.2008 |
TOYOTA | Avensis 1.8 Liftback | [1ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Avensis 1.8 VVT-i | [1ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Celica 1.8 16V | [2ZZ-GE] | 08.1999-09.2005 |
TOYOTA | Celica 1.8 VT-i 16V | [1ZZ-FE] | 08.1999-07.2005 |
TOYOTA | Corolla 1.4 | [4ZZ-FE] | 10.1999-01.2002 |
TOYOTA | Corolla 1.4 16V | [4ZZ-FE] | 02.2000-10.2001 |
TOYOTA | Corolla 1.4 16V | [4ZZ-FE] | 02.2000-11.2001 |
TOYOTA | Corolla 1.4 VVT-i | [4ZZ-FE] | 01.2002-02.2007 |
TOYOTA | Corolla 1.4 VVT-i | [4ZZ-FE] | 10.2001-10.2006 |
TOYOTA | Corolla 1.4 VVT-i | [4ZZ-FE] | 11.2001-02.2007 |
TOYOTA | Corolla 1.4 VVT-i | [4ZZ-FE] | 11.2006-11.2013 |
TOYOTA | Corolla 1.6 | [3ZZ-FE] | 02.2000-01.2002 |
TOYOTA | Corolla 1.6 | [3ZZ-FE] | 10.1999-10.2001 |
TOYOTA | Corolla 1.6 | [4ZZ-FE] | 10.1999-01.2002 |
TOYOTA | Corolla 1.6 16V | [3ZZ-FE] | 02.2000-10.2001 |
TOYOTA | Corolla 1.6 16V | [3ZZ-FE] | 10.1999-10.2001 |
TOYOTA | Corolla 1.6 VVT-i | [3ZZ-FE] | 01.2002-08.2007 |
TOYOTA | Corolla 1.6 VVT-i | [3ZZ-FE] | 01.2002-12.2006 |
TOYOTA | Corolla 1.6 VVT-i | [3ZZ-FE] | 08.2001-05.2004 |
TOYOTA | Corolla 1.6 VVT-i | [3ZZ-FE] | 10.2001-03.2008 |
TOYOTA | Corolla 1.8 VVT-i | [1ZZ-FE] | 12.2001-05.2004 |
TOYOTA | Corolla 1.8 VVTL-i TS | [2ZZ-GE] | 02.2005-02.2007 |
TOYOTA | Corolla 1.8 VVTL-i TS | [2ZZ-GE] | 10.2005-12.2006 |
TOYOTA | Corolla 1.8 VVTL-i TS | [2ZZ-GE] | 11.2001-02.2007 |
TOYOTA | MR2 1.8 VT-i 16V | [1ZZ-FE] | 10.1999-06.2007 |
TOYOTA | RAV4 1.8 | [1ZZ-FE] | 08.2000-11.2005 |
Alternatives >>>
S6061 - 1.3kW alternative
Reference Information
12053 PRSS907 DSN921 S6033 STR6446 220675 190.562.092.050 STN1236 ANM12732X J5212115 228000-7580 28100-22040 S12DE0227 28100-22041 DRS0512 228000-7581 91-29-5597 336090 6040315.1 458314 32630R LRS1630 201230D 20432513OE JS1230 281000D090 190.562.092.260 281000D050 281000D030 88212828 201230 228000-7590 28100-22030 LRS01630 2810022040 25-3159 28100-22031 190.562.092 428000-7740 2810022041 STRS907 S12DE0227A2 5040560 CST40315GSVideo/Publications
12053 190.562.092 201230 201230D 20432513OE 220675 228000-7581 228000-7590 25-3159 28100-22030 32630R 428000-7740 6040315.1 88212828 91-29-5597 CST40315GS DRS0512 J5212115 LRS01630 LRS1630 S6033 STM571 STN1236 28100-22031Add Your Number
