Associated Numbers
063280048010 0986023260 114056 190.560.092 201362 201362D 20432862 25-4071 28100-0D080 28100-0D090 28100-0D180 281000-D090 31346N 428000-0341 428000-0680 428000-4500 428000-7710 6040268 63280048 88212910 8EA012528-941 8EA738258-421 943213621010 944280801990 9715 AEY2399 CST40268 CST40268AS CST40268ES CST40268GS CST40268OS CST40268RS DENDSN920 DRS0347 DS1457 EAA-121136 JS1362 LRS02399 MRS80199 MS428000-0680 MSN8048 NEY2399 S6061 SG0987 STM571 STN1362 UD00874S Magneti Marelli Bosch ruil 11040602 EuroTec Cargo 12052 EAI 190560092 PSH 2280006310 Denso 2280006660 2280007591 show 252472 Elstock 254071 281000D010 Toyota 281000D020 281000D090 281000D180 2810022040 28100OD090 4280000680 4280000681 4280000682 4280000683 428000450 4280004500 428000771 4280007710 4280007711 4280007712 4280007713 458313 Valeo 458671 4836SP Spidan 600000170090 63280048010 8080199F Friesen 8EA738258421 Hella 910347 EDR 913935 94857220 Chevrolet CEVAM A20550 ATL A78460 ATS385 ATK ATS392 Remy DRS3935 DSN920 F042S00281 HJS1362 HC J5212122 Herth Buss LRS01509 Lucas LRS1509 MS4280000680 N5212116 Nipparts OSM11357 Optimum OSM11776 RAS31458 SP4836 STR24099 Stabeco STR8205 Unipoint T521A04 NPS TRS038 TWA 70-8117 70-8117g snj214 dxs4050 190.553.092.210 190.553.092.010 113271 0001107433 0001107434 190.553.092.280 20401052BN 20401052OE 25-4248 28100-0D030 28100-0D110 28100-0D130 28100-22040 28100-22041 3929 BOS0001107433 DRT1060 DT2170 F004A94434 LRS02576 LRS2576 UD18652SSpecifications
| Kilowatt | 1.3 kW |
| Length (L.1) | 193 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 16 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Avensis 1.6 VVTi | [3ZZ-FE] | 04.2003- |
| TOYOTA | Avensis 1.8 | [1ZZ-FE] | 04.2003- |
| TOYOTA | Corolla 1.6 Verso | [3ZZ-FE] | 04.2004- |
| TOYOTA | Corolla 1.8 Verso | [1ZZ-FE] | 04.2004- |
| TOYOTA | Corolla 1.8 Verso | 03.2004- | |
| TOYOTA | Corolla 1.8 Verso | 09.2001-05.2004 |
Reference Information
201362D 20432862BN 31346N DSN920 EAA-121136 S12DE0136A2 201362 281000-D090 6040268 LRS02399 2810022031 28100-0D090 CST40268AS 2810022030 5040017 336072 201362M 428000-4500 20432862OE STR70583 STRS219 28100-0D130 PRSS219 63280048010 DENDSN920 MSN8048 DS1457 STM571 000986023260 220542 MS428000-0680 F042200010 281000D030 28100-22030 J5212122 2810022040 28100-0D180 STN1362 28100-22031 2810022041 3T385 SG0987 UD00874S NEY2399 986023260 190.560.092.050 12052 9.44281E+11 JS1362 190.560.092.058 MRS80199 190.560.092.059 28100-22040 CST40268GS 28100-0D030 28100-22041 428000-7710 428000-0680 114056 9715 000F042200010 CGB-54071 25-4071 8EA012528-941 88212910 LRS2399 S6061 190.560.092.260 MTT385 STR6413 MAV421610 281000D130 6040268.1 ANM12567X 28100-0D080 446527 DRS0347 003-T385Video/Publications
003-T385 063280048010 0986023260 114056 190.560.092 201362 201362D 20432862 25-4071 28100-0D080 28100-0D090 28100-0D180 281000-D090 31346N 3T385 428000-0341 428000-0680 428000-4500 428000-7710 6040268 88212910 8EA012528-941 8EA738258-421 943213621010 944280801990 9715 AEY2399 CST40268 CST40268AS CST40268ES CST40268GS CST40268OS CST40268RS DENDSN920 DRS0347 DS1457 EAA-121136 JS1362 LRS02399 LRS2399 MAV421610 MRS80199 MS428000-0680 MSN8048 MTT385 NEY2399 RNL28100-0D090 RNL428000-4500 S6061 SG0987 STM571 STN1362 STRS219 UD00874S 220542Add Your Number
