Associated Numbers
- Arrowhead ND028000-6063, ND9702809-606, SND0739
- Denso 028000-6060, 028000-6061, 028000-6062, 028000-6063, 9702809-606
- J&N Electrical Products 410-52499
- Kubota 15611-63011, 15611-63012, 15611-63013
- Lester 19746
- Lucas Electric LRS01175
- Mustang 425-34229
- Other OEMS 425-34229
- SAM-C11080
-
028000-606, 028000-6060, 028000-6061, 028000-6062, 028000-6063, 9702809-606 Farcom 105095 IAT 610-103 Industry 19746 J&N 410-52499 Kubota 15611-63010, 15611-63011, 15611-63012, 15611-63013 Mustang 42534229 -
WAI New 19746N Alltech 126-19746 American Power Systems APS19746 Andre Niermann 015611 Armature G Roy 19746 Atelier Dynamo S190-835 Bepco 80-19746 Canadian Tire 0195615 Casco CST40156AS Delphi SX3630 Denso 028000-6060, 028000-6061, 028000-6063 EGI S-19746 Elpar Industries 012803677 IAT 610-103 Ingersoll Rand 22463939 Kubota 15611-63010, 15611-63011, 15611-63012, 15611-63013 Lester 19746 Lucas Electrical Europe LRS01175 Metro Auto Industrial 19746N Mondial 70-938-50 Mustang Marine 42534229 Our Part Number 19746N Part # 19746 PASCO S-1000835 PIC Old 190-832A Power Select 19746N Powerite Automotive 19746 Quality Rebuilders 19746 Raw Power 19746N Road Warrior 19746N Stratoline 80-19746 TSA 19746N UCP Remanufactured 19746 Wood Auto Supplies STR70112 Zorko 19746
|
0280006060 |
Denso |
|---|---|
|
0280006061 |
Denso |
|
0280006062 |
Denso |
|
0280006063 |
Denso |
|
0280006064 |
Denso |
|
0280007800 |
Denso |
|
0280007801 |
Denso |
|
0280007802 |
Denso |
|
0280007803 |
Denso |
|
114259 |
HC-Cargo |
|
114711 |
HC-Cargo |
|
1552763010 |
Kubota |
|
1552763011 |
Kubota |
|
1552763012 |
Kubota |
|
1552763013 |
Kubota |
|
1552763014 |
Kubota |
|
1552763015 |
Kubota |
|
1561163010 |
Kubota |
|
1561163011 |
Kubota |
|
1561163012 |
Kubota |
|
1561163013 |
Kubota |
|
1561163014 |
Kubota |
|
1561163015 |
Kubota |
|
19746N |
WAI |
|
24625129 |
Dixie |
|
24625133 |
Dixie |
|
690527112 |
PSH |
|
911295536 |
Wilson |
|
91295536 |
Wilson |
|
9702809606 |
Denso |
|
9702809780 |
Denso |
|
AKS971 |
ATK |
|
DRS0506 |
Delco Remy |
|
F032114259 |
HC-Cargo |
|
F032114711 |
HC-Cargo |
|
LRS01175 |
Lucas |
|
LRS1175 |
Lucas |
|
S8582 |
Dixie |
|
S8593 |
Dixie |
|
STR70112 |
Wood Auto |
|
STR70393 |
Wood Auto |
|
WOOSTR70112 |
Wood Auto |
|
WOOSTR70393 |
Wood Auto |
Specifications
NOT FOR WET CLUTCH APPLICATIONS
| Kilowatt | 2.5 kW |
| Length (L.1) | 302.00 mm |
| Mount Hole Center - Center (O.1) | 105.00 mm |
| Mount Hole Diameter (C.1) | 11.00 mm |
| Mount Hole Diameter (C.2) | 11.00 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 25.00 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KUBOTA |
Reference Information
| 280006060 | Denso |
| 280006061 | Denso |
| 280006062 | Denso |
| 280006063 | Denso |
| 280006064 | Denso |
| 280007800 | Denso |
| 280007801 | Denso |
| 280007802 | Denso |
| 280007803 | Denso |
| 114259 | HC-Cargo |
| 114711 | HC-Cargo |
| 1552763010 | Kubota |
| 1552763011 | Kubota |
| 1552763012 | Kubota |
| 1552763013 | Kubota |
| 1552763014 | Kubota |
| 1552763015 | Kubota |
| 1561163010 | Kubota |
| 1561163011 | Kubota |
| 1561163012 | Kubota |
| 1561163013 | Kubota |
| 1561163014 | Kubota |
| 1561163015 | Kubota |
| 19746N | WAI |
| 24625129 | Dixie |
| 24625133 | Dixie |
| 690527112 | PSH |
| 911295536 | Wilson |
| 91295536 | Wilson |
| 9702809606 | Denso |
| 9702809780 | Denso |
| AKS971 | ATK |
| DRS0506 | Delco Remy |
| F032114259 | HC-Cargo |
| F032114711 | HC-Cargo |
| LRS01175 | Lucas |
| LRS1175 | Lucas |
| S8582 | Dixie |
| S8593 | Dixie |
| STR70112 | Wood Auto |
| STR70393 | Wood Auto |
| WOOSTR70112 | Wood Auto |
| WOOSTR70393 | Wood Auto |
