Associated Numbers
0001109128 Bosch 0058402260 Lombardini 11131391 Mahle 5840204 Farymann diesel 58402040 5840226 58402260 584226 72735763 750004102 PSH AZE1236 DRS0597 Remy ED0058402260 IS1138 LETIS1138 Wood Auto MAHMS135 MS135 STR60691 11.131.391 OTHER SGM-A10050 70-2632 ms135 12V 1 0kW MS 135Specifications
| Kilowatt | 1.0 kW |
| Length (L.1) | 197 mm |
| Mount Hole Center - Center (O.1) | 97 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 mm |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 15 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LOMBARDINI |
Reference Information
11.131.391, AZE1236, IS1138, MS135
