Price:
NZ$ 550.78 including GST
NZ$ 478.94 excluding GST
or four payments of $137.70
with
Learn More
UOM:
each
Product Code:
S0188(BOSCH)
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 2.00 kW |
| Length (L.1) | 237.00 mm |
| Mount Hole Center - Center (O.1) | 110.00 mm |
| Mount Hole Diameter (C.1) | 11.00 mm |
| Mount Hole Diameter (C.2) | 11.00 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 20.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ASV | PT-30 1.5 | 3013 | 01.2008-12.2009 |
| ASV | PT-30 1.5 | 403C-15 | 01.2008-12.2009 |
| ASV | PT-30 1.5 | 403D-15 | 01.2008-12.2009 |
| ASV | PT-50 2.2 | 404C-22 | 01.2008-12.2009 |
| ASV | PT-60 2.2 | 404C-22T | 01.2008-12.2009 |
| ASV | RC-30 1.5 | 3013 | 01.2000-12.2009 |
| ASV | RC-30 1.5 | 403C-15 | 01.2000-12.2009 |
| ASV | RC-30 1.5 | 403D-15 | 01.2000-12.2009 |
| ASV | RC 50 | 404C | - |
| ASV | RC-50 2.2 | 404C-22 | 01.2002-12.2009 |
| ASV | RC-60 2.2 | 404C-22T | 01.2004-12.2009 |
| ASV | RT-30 1.5 | 403D-15 | 01.2015-12.2021 |
| ASV | RT-50 2.2 | 404D-22 | 01.2015-12.2021 |
| ASV | RT-60 2.2 | 404D-22T | 01.2015-12.2021 |
| CATERPILLAR | 216 | 3034 | 01.1999-12.2004 |
| CATERPILLAR | 216 2.2 | 3024C | 01.2002-12.2004 |
| CATERPILLAR | 216B | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 216B 2.2 | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 216B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 226 | 3034 | 01.1999-12.2004 |
| CATERPILLAR | 226B | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 226B 2.2 | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 226B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 228 | 3034 | 01.1999-12.2004 |
| CATERPILLAR | 232 | 3024C | 01.1999-12.2004 |
| CATERPILLAR | 232 2.2 | 3024C | 01.2002-12.2004 |
| CATERPILLAR | 232B | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 232B 2.2 | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 232B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 242B | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 242B 2.2 | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 242B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 247B | 3024C | - |
| CATERPILLAR | 247B 2.2 | 3024C | 01.2003-12.2008 |
| CATERPILLAR | 247B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 257B | 3024C | 01.2004-12.2008 |
| CATERPILLAR | 257B 2.2 | 3024C | 01.2004-12.2007 |
| CATERPILLAR | 257B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 334D | 3013 | 01.1998-12.2004 |
| CATERPILLAR | 334D | 3014 | 01.2002-12.2005 |
| CATERPILLAR | 335D | 3013 | 01.1998-12.2004 |
| CATERPILLAR | 335D | 3014 | 01.2000-12.2005 |
| CATERPILLAR | BB621C 2.2 | C2.2 | 01.2005-12.2010 |
| CATERPILLAR | CB214D 1.5 | 3013 | 01.1999-12.2005 |
| CATERPILLAR | CB214E 1.5 | 3013C | 01.2003-12.2009 |
| CATERPILLAR | CB22 1.5 | 3013C | 01.2008-12.2013 |
| CATERPILLAR | CB224D 1.5 | 3013 | 01.1999-12.2005 |
| CATERPILLAR | CB224E 1.5 | 3013C | 01.2003-12.2009 |
| CATERPILLAR | CB225D 1.5 | 3013 | 01.1999-12.2005 |
| CATERPILLAR | CB225E 1.5 | 3013C | 01.2003-12.2009 |
| CATERPILLAR | CB22B 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB24 1.5 | 3013C | 01.2008-12.2013 |
| CATERPILLAR | CB24B 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB24B XT 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB32 1.5 | 3013C | 01.2008-12.2013 |
| CATERPILLAR | CB32B 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB334D | 3013 | 01.1998-12.2004 |
| CATERPILLAR | CB334D | 3014 | 01.2002-12.2005 |
| CATERPILLAR | CB-334D 1.5 | 3013 | 01.1998-12.2004 |
| CATERPILLAR | CB334D 1.5 | 3013 | 01.1998-12.2004 |
| CATERPILLAR | CB-334D 2.0 | 3014 | 01.2002-12.2005 |
| CATERPILLAR | CB334D 2.0 | 3014 | 01.2002-12.2006 |
| CATERPILLAR | CB334E 1.5 | 3013C | 01.2004-12.2008 |
| CATERPILLAR | CB334E 2.2 | 3024C | 01.2004-12.2009 |
| CATERPILLAR | CB334E XW 2.2 | 3024C | 01.2004-12.2009 |
| CATERPILLAR | CB335D | 3013 | 01.1998-12.2004 |
| CATERPILLAR | CB335D | 3014 | 01.2000-12.2005 |
| CATERPILLAR | CB-335D 1.5 | 3013 | 01.1998-12.2004 |
| CATERPILLAR | CB335D 1.5 | 3013 | 01.1998-12.2004 |
| CATERPILLAR | CB-335D 2.0 | 3014 | 01.2000-12.2005 |
| CATERPILLAR | CB335D 2.0 | 3014 | 01.2000-12.2005 |
| CATERPILLAR | CB335E 1.5 | 3013C | 01.2004-12.2008 |
| CATERPILLAR | CB335E 2.2 | 3024C | 01.2004-12.2009 |
| CATERPILLAR | CB34 | C2.2 | 01.2007-12.2013 |
| CATERPILLAR | CB-34 2.2 | C2.2 | 01.2007-12.2013 |
| CATERPILLAR | CB34XW | C2.2 | 01.2007-12.2013 |
| CATERPILLAR | CB-34 XW 2.2 | C2.2 | 01.2007-12.2013 |
| CATERPILLAR | CC24 1.5 | 3013 | 01.2007-12.2013 |
| CATERPILLAR | CC24B 1.5 | C1.5 | 01.2013-12.2020 |
| CATERPILLAR | CC34 | C2.2 | 01.2007-12.2013 |
| CATERPILLAR | CC34 2.2 | C2.2 | 01.2007-12.2013 |
| GENIE | TML-4000 | 403D-11G | 01.2010-12.2012 |
| HUMMER | H2 Closed Off-Road Vehicle 6.0 AWD | LQ4(364CUV8) | 09.2003-12.2004 |
| JCB | 135 2.2 | 404D-22 | 01.2012-12.2019 |
| JCB | 150 2.2 | 104-22 | 01.1997-12.1999 |
| JCB | 150 2.2 | 404D-22 | 01.2012-12.2016 |
| JCB | 155 2.2 | 404D-22 | 01.2011-12.2019 |
| JCB | 160 2.2 | 104-22 | 01.2000-12.2001 |
| JCB | 160 2.2 | 404C-22 | 01.2000-12.2012 |
| JCB | 160 2.2 | 404C-22T | 01.2007-12.2012 |
| JCB | 160 2.2 | 404D-22 | 01.2007-12.2012 |
| JCB | 160 2.2 | 404D-22T | 01.2007-12.2012 |
| JCB | 165 2.2 | 104-22 | 01.1996-12.2000 |
| JCB | 170 2.2 | 104-22 | 01.1999-12.2001 |
| JCB | 170 2.2 | 404C-22 | 01.1999-12.2012 |
| JCB | 170 2.2 | 404C-22T | 01.2006-12.2012 |
| JCB | 170 2.2 | 404D-22 | 01.2006-12.2012 |
| JCB | 170 2.2 | 404D-22T | 01.2006-12.2012 |
| JCB | 175 2.2 | 404D-22 | 01.2012-12.2015 |
| JCB | 175 2.2 | 404D-22T | 01.2012-12.2015 |
| JCB | 180 2.2 | 404C-22 | 01.2006-12.2012 |
| JCB | 180 2.2 | 404C-22T | 01.2005-12.2012 |
| JCB | 180 2.2 | 404D-22 | 01.2006-12.2012 |
| JCB | 180 2.2 | 404D-22T | 01.2006-12.2012 |
| JCB | 190 2.2 | 404D-22 | 01.2012-12.2015 |
| JCB | 190 2.2 | 404D-22T | 01.2012-12.2015 |
| JCB | 1CX 2.2 | 404C-22 | 01.1996-12.2001 |
| JCB | 1CX 2.2 | 404D-22 | 01.1996-12.2019 |
| JCB | 205 2.2 | 404D-22 | 01.2012-12.2016 |
| JCB | 208S 2.2 | 104-22 | 01.1997-12.2007 |
| JCB | 208S 2.2 | 404C-22 | 01.1997-12.2007 |
| JCB | 208S 2.2 | 404D-22 | 01.1997-12.2007 |
| JCB | 354 2.2 | 404C-22T | 01.2006-12.2009 |
| JCB | 360 2.2 | 404C-22T | 01.2008-12.2009 |
| JCB | 3DX 2.2 | 404D-22 | 01.2011-12.2012 |
| JCB | 48Z-1 2.2 | 404D-22 | 01.2016-12.2020 |
| JCB | 515-40 2.2 | 404C-22 | 01.2002-12.2006 |
| JCB | 51R-1 2.2 | 404D-22 | 01.2016-12.2020 |
| JCB | 520-40 2.2 | 404C-22 | 01.2003-12.2011 |
| JCB | 520-40 2.2 | 404D-22 | 01.2008-12.2019 |
| JCB | 520-50 2.2 | 404D-22 | 01.2012-12.2014 |
| JCB | 55Z-1 2.2 | 404D-22 | 01.2016-12.2020 |
| JCB | 57C-1 2.2 | 404D-22 | 01.2016-12.2020 |
| JCB | 65R-1 2.2 | 404D-22 | 01.2014-12.2020 |
| JCB | 802 1.3 | 103-13 | 01.1985-12.1997 |
| JCB | 802 1.5 | 103-15 | 01.1985-12.1997 |
| JCB | 802.4 1.5 | 103-15 | 01.1997-12.2000 |
| JCB | 802.4 Super 1.5 | 103-15 | 01.2000-12.2003 |
| JCB | 8025 CTS | 403C-15 | 01.2006-12.2013 |
| JCB | 8025 CTS 1.5 | 403D-15 | 01.2006-12.2020 |
| JCB | 8025 ZTS 1.5 | 403C-15 | 01.2006-12.2010 |
| JCB | 8025 ZTS 1.5 | 403D-15 | 01.2006-12.2020 |
| JCB | 802.7 Plus 1.5 | 103-15 | 01.1997-12.2000 |
| JCB | 802.7 Super 1.5 | 103-15 | 01.2000-12.2003 |
| JCB | 802.7 Super 1.5 | 403C-15 | 01.2003-12.2006 |
| JCB | 8027 Z 1.5 | 403C-15 | 01.2002-12.2006 |
| JCB | 802 Super 1.5 | 403C-15 | 01.2003-12.2006 |
| JCB | 8030 ZTS 1.5 | 403C-15 | 01.2006-12.2010 |
| JCB | 8030 ZTS 1.5 | 403D-15 | 01.2010-12.2020 |
| JCB | 8032 Z 1.5 | 403C-15 | 01.2002-12.2006 |
| JCB | 8035 ZTS 1.5 | 403C-15 | 01.2006-12.2010 |
| JCB | 8035 ZTS 1.5 | 403D-15 | 01.2006-12.2010 |
| JCB | 8035 ZTS 1.7 | 403D-17 | 01.2006-12.2020 |
| JCB | 803 Magnum 1.5 | 403C-15 | 01.2003-12.2006 |
| JCB | 803 Plus 1.5 | 103-15 | 01.1997-12.2003 |
| JCB | 803 Plus 1.5 | 403C-15 | 01.2003-12.2006 |
| JCB | 803 Super 1.5 | 103-15 | 01.1999-12.2003 |
| JCB | 803 Super 1.5 | 403C-15 | 01.2003-12.2006 |
| JCB | 8040 ZTS 2.2 | 404C-22 | 01.2006-12.2012 |
| JCB | 8040 ZTS 2.2 | 404D-22 | 01.2006-12.2017 |
| JCB | 8045 ZTS 2.2 | 404C-22 | 01.2006-12.2013 |
| JCB | 8045 ZTS 2.2 | 404D-22 | 01.2006-12.2017 |
| JCB | 804 Plus 1.5 | 103-15 | 01.1997-12.1999 |
| JCB | 804 Super 1.5 | 103-15 | 01.1998-12.2003 |
| JCB | 804 Super 1.5 | 403C-15 | 01.2003-12.2006 |
| JCB | 8050 RTS 2.2 | 404D-22 | 01.2010-12.2017 |
| JCB | 8050 ZTS 2.2 | 404D-22 | 01.2010-12.2017 |
| JCB | 8052 | 01.2001- | |
| JCB | 8052 2.2 | 104-22 | 01.1999-12.2003 |
| JCB | 8052 2.2 | 404C-22 | 01.2003-12.2008 |
| JCB | 8055 RTS 2.2 | 404D-22 | 01.2011-12.2016 |
| JCB | 8055 ZTS 2.2 | 404D-22 | 01.2011-12.2016 |
| JCB | Midi CX 2.2 | 404C-22 | 01.2006-12.2015 |
| JCB | Midi CX 2.2 | 404D-22 | 01.2006-12.2015 |
| JCB | TLT20D 2.2 | 104-22 | 01.1998-12.2000 |
| JCB | TLT20D 2.2 | 404C-22 | 01.1998-12.2000 |
| JCB | TLT25D 2.2 | 104-22 | 01.1997-12.2008 |
| JCB | TLT25D 2.2 | 404C-22 | 01.1997-12.2008 |
| JCB | TLT25D 2.2 | 404D-22 | 01.2008-12.2012 |
| JCB | TLT30D 2.2 | 404C-22 | 01.1999-12.2008 |
| JCB | TLT30D 2.2 | 404C-22T | 01.2006-12.2008 |
| JCB | TLT30D 2.2 | 404D-22 | 01.2008-12.2012 |
| JCB | TLT35D 2.2 | 404C-22T | 01.2004-12.2008 |
| KHD | Various Models | - | |
| LINCOLN | K1643-11 Classic 300D | 404D-22 | - |
| LINCOLN | K1643-3 Classic 300D | 404C-22 | - |
| LINCOLN | K1643-4 Classic 300D | 404C-22 | - |
| LINCOLN | K1643-7 Classic 300D | 404D-22 | - |
| LINCOLN | K1643-8 Classic 300D | 404D-22 | - |
| PERKINS | Engine | 404C-22 | - |
| PERKINS | Engine 0.7 | 403C-07 | 01.2004-12.2014 |
| PERKINS | Engine 1.1 | 403C-11G | 01.2004-12.2014 |
| PERKINS | Engine 1.3 | 103-13 | - |
| PERKINS | Engine 1.5 | 103-15 | - |
| PERKINS | Engine 2.0 | 104-19 | - |
| PERKINS | Engine 2.2 | 104-22 | - |
| PERKINS | Engine 2.2 | 134ci | 01.2002-12.2014 |
| PERKINS | Engine 2.2 | 404C-22 | 01.2000-12.2010 |
| PERKINS | Engine 2.2 | 404C-22G | - |
| PERKINS | Engine 2.2 | 404C-22T | 01.2002-01.0001 |
| TEREX | PT-30 1.5 | 403D-15 | 01.2009-12.2017 |
| TEREX | PT-50 2.2 | 404C-22 | 01.2009-12.2017 |
| TEREX | PT-60 2.2 | 404D-22T | 01.2009-12.2017 |
| TEREX | R070T 2.2 | 404C-22 | 01.2014-12.2017 |
| TEREX | R190T 2.2 | 404C-22 | 01.2014-12.2017 |
