Price:
NZ$ 728.07 including GST
NZ$ 633.10 excluding GST
or four payments of $182.02
with
Learn More
UOM:
each
Product Code:
A3152
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 13.50 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 185.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61.00 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.2) | 50.00 mm |
| Pulley to Mount Distance (A) | 30.00 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 110 | 9HL(DV6C) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 110 | 9HR(DV6C) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 115 | 9HL(DV6C) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 90 | 9HJ(DV6DTEDM) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 90 | 9HP(DV6DTED) | 07.2010- |
| CITROËN | BERLINGO MULTISPACE (B9) 1.6 HDi 110 | 9HL(DV6C) | 07.2010- |
| CITROËN | BERLINGO MULTISPACE (B9) 1.6 HDi 110 | 9HR(DV6C) | 07.2010- |
| CITROËN | BERLINGO MULTISPACE (B9) 1.6 HDi 115 | 9HR(DV6C) | 07.2010- |
| CITROËN | C4 AIRCROSS 1.6 HDi 115 | 9HD(DV6C) | 04.2012- |
| CITROËN | C4 AIRCROSS 1.6 HDi 115 AWC | 9HL(DV6C) | 05.2012- |
| CITROËN | C4 GRAND PICASSO I (UA_) 1.6 HDi 110 | 9HR(DV6C) | 09.2010-08.2013 |
| CITROËN | C4 II (NC_) 1.6 HDi 110 | 9HR(DV6C) | 11.2009- |
| CITROËN | C4 II (NC_) 1.6 HDi 115 | 9HD(DV6C) | 07.2012- |
| CITROËN | C4 II (NC_) 1.6 HDi 90 | 9HJ(DV6DTEDM) | 11.2009- |
| CITROËN | C4 II (NC_) 1.6 HDi 90 | 9HP(DV6DTED) | 11.2009- |
| CITROËN | C4 PICASSO I MPV (UD_) 1.6 HDi 110 | 9HR(DV6C) | 09.2010-08.2013 |
| CITROËN | C5 III Break (RW_) 1.6 HDi 110 | 9HL(DV6C) | 07.2010-05.2012 |
| CITROËN | C5 III Break (RW_) 1.6 HDi 110 | 9HR(DV6C) | 07.2010-05.2012 |
| CITROËN | C5 III Break (RW_) 1.6 HDi 115 | 9HL(DV6C) | 06.2012-06.2015 |
| CITROËN | C5 III Break (RW_) 1.6 HDi 115 | 9HR(DV6C) | 06.2012-06.2015 |
| CITROËN | C5 III (RD_) 1.6 HDi 110 (RD9HL0, RD9HR8, RD9HRA) | 9HL(DV6C) | 07.2010-05.2012 |
| CITROËN | C5 III (RD_) 1.6 HDi 110 (RD9HL0, RD9HR8, RD9HRA) | 9HR(DV6C) | 07.2010-05.2012 |
| CITROËN | C5 III (RD_) 1.6 HDi 115 (RD9HRA, RD9HLA, RD9HL0) | 9HL(DV6C) | 01.2012-06.2015 |
| CITROËN | C5 III (RD_) 1.6 HDi 115 (RD9HRA, RD9HLA, RD9HL0) | 9HR(DV6C) | 01.2012-06.2015 |
| CITROËN | DS4 (NX_) 1.6 HDi 110 | 9HR(DV6C) | 04.2011-07.2015 |
| PEUGEOT | 208 I (CA_, CC_) 1.6 HDi | 9HD(DV6C) | 03.2012-12.2019 |
| PEUGEOT | 3008 I MPV (0U_) 1.6 HDi | 9HR(DV6C) | 12.2009-08.2016 |
| PEUGEOT | 308 CC (4B_) 1.6 HDi | 9HR(DV6C) | 06.2009-12.2014 |
| PEUGEOT | 308 I (4A_, 4C_) 1.6 HDi | 9HJ(DV6DTEDM) | 11.2009-10.2014 |
| PEUGEOT | 308 I (4A_, 4C_) 1.6 HDi | 9HP(DV6DTED) | 11.2009-10.2014 |
| PEUGEOT | 308 I (4A_, 4C_) 1.6 HDi | 9HR(DV6C) | 12.2009-10.2014 |
| PEUGEOT | 308 SW I (4E_, 4H_) 1.6 HDi | 9HP(DV6DTED) | 11.2009-10.2014 |
| PEUGEOT | 308 SW I (4E_, 4H_) 1.6 HDi | 9HR(DV6C) | 12.2009-10.2014 |
| PEUGEOT | 508 I (8D_) 1.6 HDi | 9HD(DV6CTED) | 02.2012-12.2018 |
| PEUGEOT | 508 I (8D_) 1.6 HDi | 9HL(DV6C) | 11.2010-12.2018 |
| PEUGEOT | 508 I (8D_) 1.6 HDi | 9HR(DV6C) | 11.2010-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HL(DV6C) | 02.2012-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HL(DV6C) | 11.2010-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HR(DV6C) | 02.2012-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HR(DV6C) | 11.2010-12.2018 |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi | 9HT(DV6BTED4) | 04.2008- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi | 9HT(DV6BUTED4) | 04.2008- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi | 9HW(DV6BTED4) | 04.2008- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi | 9HZ(DV6TED4) | 04.2008- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi 16V | 9HS(DV6TED4BU) | 04.2008- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi 16V | 9HX(DV6AUTED4) | 04.2008- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi 90 | 9HJ(DV6DTEDM) | 04.2010- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi 90 | 9HP(DV6DTED) | 04.2010- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi | 9HL(DV6C) | 08.2010- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi | 9HZ(DV6TED4) | 04.2008- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi 16V | 9HV(DV6TED4B) | 04.2008- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi 90 | 9HJ(DV6DTEDM) | 04.2010- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi 90 | 9HP(DV6DTED) | 04.2010- |
| SKODA | FABIA II Combi (545) 1.2 | BZG | 10.2007-12.2014 |
| SKODA | FABIA II Combi (545) 1.2 | CEVA | 10.2007-12.2014 |
| SKODA | FABIA II Combi (545) 1.2 | CGPA | 10.2007-12.2014 |
| SKODA | FABIA II Combi (545) 1.2 | CHTA | 10.2007-12.2014 |
| SKODA | ROOMSTER (5J7) 1.2 | BZG | 01.2007-05.2015 |
| SKODA | ROOMSTER (5J7) 1.2 | CGPA | 01.2007-05.2015 |
| SKODA | ROOMSTER Praktik (5J) 1.2 | BZG | 03.2007-05.2015 |
| SKODA | ROOMSTER Praktik (5J) 1.2 | CGPA | 03.2007-05.2015 |
| VW | POLO V (6R1, 6C1) 1.2 | CGPA | 06.2009-05.2014 |
| VW | POLO V (6R1, 6C1) 1.2 | CGPB | 06.2009-05.2014 |
