Price:
NZ$ 561.74 including GST
NZ$ 488.47 excluding GST
or four payments of $140.44
with
Learn More
UOM:
each
Product Code:
A2149S
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 60 A |
| Bottom Mounting Foot Width (B) | 13.00 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 257.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 80.00 mm |
| Plug Code | PL_2004 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 16.00 mm |
| Pulley Outside Diameter (O.D.1) | 82.00 mm |
| Pulley Outside Diameter (O.D.2) | 49.00 mm |
| Pulley to Mount Distance (A) | 48.00 mm |
| Pulley Type | Solid |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | D-MAX I (TFR, TFS) 2.5 DiTD 4x4 (TFS54) | 4JA1-TC | 05.2002-06.2012 |
| ISUZU | D-MAX I (TFR, TFS) 2.5 DiTD (TFR86_, TFR54_) | 4JA1-TC | 10.2002-06.2012 |
| ISUZU | D-MAX I (TFR, TFS) 3.0 DiTD 4x4 (TFS77H) | 4JH1-TC | 05.2002-06.2012 |
