Price:
NZ$ 409.58 including GST
NZ$ 356.16 excluding GST
or four payments of $102.40
with
Learn More
UOM:
each
Product Code:
A01097S
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 50.00 mm |
| Diameter (D.1) | 10.00 mm |
| Diameter (D.2) | 10.00 mm |
| Diameter (D.3) | 8.00 mm |
| Length (L.1) | 170.00 mm |
| Plug Code | PL_9105 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 13.50 mm |
| Pulley Outside Diameter (O.D.1) | 90.00 mm |
| Pulley Outside Diameter (O.D.2) | 55.00 mm |
| Pulley to Mount Distance (A) | 76.00 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SKODA | 105,120 (742) 1.0 105 S, L | 742.10 | 08.1976-12.1990 |
| SKODA | 105,120 (742) 1.0 105 S, L, GL | 742.10 | 08.1976-08.1983 |
| SKODA | 105,120 (742) 1.2 120 L | 742.12X | 08.1976-12.1990 |
| SKODA | 105,120 (742) 1.2 120 LS | 742.12X | 08.1976-12.1990 |
| SKODA | 105,120 (744) 1.0 105 S, L | 742.10 | 02.1988-12.1990 |
| SKODA | 105,120 (744) 1.0 105 S, L, LS | 742.10 | 10.1983-12.1990 |
| SKODA | 105,120 (744) 1.2 120 GLS | 742.12X | 02.1983-12.1990 |
| SKODA | 105,120 (744) 1.2 120 L | 742.12 | 08.1987-12.1990 |
| SKODA | 105,120 (744) 1.2 120 L | 742.12 | 10.1983-12.1990 |
| SKODA | 130 G,GL (S136) | 781.136 | 02.1985-10.1991 |
| SKODA | 130 GL | 743.13 | 08.1987-10.1991 |
| SKODA | 130 GL (S135) | 135/8 | 01.1987-10.1991 |
| SKODA | 130 L,GL | 742.13 | 02.1985-10.1991 |
| SKODA | RAPID (120G, 130G, 135G) 1.2 (120G) | 742.12X | 02.1983-12.1990 |
| SKODA | RAPID (120G, 130G, 135G) 1.3 (130G) | 742.13 | 03.1985-08.1988 |
| SKODA | RAPID (120G, 130G, 135G) 1.3 (130G) | 743.13 | 08.1987-10.1991 |
| SKODA | RAPID (120G, 130G, 135G) 1.3 S (135GL) | 135/8 | 09.1984-12.1990 |
| ZETOR | 10011 4.6 | Z-8002 | 01.1997- |
| ZETOR | 10045 4.6 | Z-8002 | 01.1980-12.1984 |
| ZETOR | 12011 6.8 | Z-8601 | 01.1997- |
| ZETOR | 12045 6.8 | Z-8601 | 01.1997- |
| ZETOR | 12045 6.8 | Z8601 | 01.1974-12.1984 |
| ZETOR | 16045 6.8 | Z-8602 | 01.1997- |
| ZETOR | 4712 2.7 | Z-4701 | 01.1997- |
| ZETOR | 4718 2.6 | Z-4701 | 01.1997- |
| ZETOR | 4911 2.7 | Z-4901 | 01.1997- |
| ZETOR | 5011 2.7 | Z-5001 | 01.1997- |
| ZETOR | 5211 2.7 | Z-5201 | 01.1984- |
| ZETOR | 5245 2.7 | Z-5201 | 01.1984- |
| ZETOR | 5320 3.6 | Z-7201 | 01.1992- |
| ZETOR | 5321 3.6 | Z-7202 | 01.1997- |
| ZETOR | 5340 3.6 | Z-7201 | 01.1992- |
| ZETOR | 5341 3.6 | Z-7201 | 01.1997- |
| ZETOR | 5711 3.1 | Z-5501 | 01.1974-12.1977 |
| ZETOR | 5711 3.1 | Z-5501 | 01.1997- |
