Brand new AS-PL Alternator
PREMIUM LINE
Mitsubishi
MITSUBISHI
Price:
NZ$ 1,050.80 including GST
NZ$ 913.74 excluding GST
or four payments of $262.70
with
Learn More
Product Code:
S5597(MITSUBISHI)
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.70 kW |
| Length (L.1) | 230.00 mm |
| Mount Hole Center - Center (O.1) | 17.00 mm |
| Mount Hole Center - Center (O.2) | 134.00 mm |
| Mount Hole Center - Center (O.3) | 122.00 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10X1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 15.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | TALENTO Bus (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| FIAT | TALENTO Bus (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| FIAT | TALENTO Platform/Chassis (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| FIAT | TALENTO Platform/Chassis (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| FIAT | TALENTO Van (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| FIAT | TALENTO Van (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| FIAT | TALENTO Van (296_) 2.0 EcoJet | M9R710 | 07.2019- |
| NISSAN | NV300 Kombi (X82) 2.0 dCi 110 | M9R714 | 05.2021- |
| NISSAN | NV300 Kombi (X82) 2.0 dCi 145 | M9R710 | 07.2019- |
| NISSAN | NV300 Kombi (X82) 2.0 dCi 150 | M9R714 | 05.2021- |
| NISSAN | NV300 Kombi (X82) 2.0 dCi 170 | M9R710 | 07.2019- |
| NISSAN | NV300 Kombi (X82) 2.0 dCi 170 | M9R714 | 07.2019- |
| NISSAN | NV300 Van (X82) 2.0 dCi 110 | M9R714 | 05.2021- |
| NISSAN | NV300 Van (X82) 2.0 dCi 145 | M9R710 | 07.2019- |
| NISSAN | NV300 Van (X82) 2.0 dCi 150 | M9R714 | 05.2021- |
| NISSAN | NV300 Van (X82) 2.0 dCi 170 | M9R710 | 07.2019- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 110 | M9R714 | 11.2021- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 110 | M9R717 | 11.2021- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 130 | M9R714 | 11.2021- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 150 | M9R714 | 11.2021- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 150 | M9R717 | 11.2021- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 170 | M9R714 | 11.2021- |
| NISSAN | PRIMASTAR Van (X82) 2.0 dCi 170 | M9R717 | 11.2021- |
| RENAULT | ESPACE V (JR_) 2.0 Blue dCi 160 (JRAM) | M9R650 | 10.2018-03.2023 |
| RENAULT | ESPACE V (JR_) 2.0 Blue dCi 160 (JRAM) | M9R712 | 10.2018-03.2023 |
| RENAULT | ESPACE V (JR_) 2.0 Blue dCi 200 (JRAL) | M9R650 | 10.2018-03.2023 |
| RENAULT | KOLEOS II (HC_) 2.0 BLUE dCi 190 4WD (HCAN) | M9R730 | 06.2019- |
| RENAULT | KOLEOS II (HC_) 2.0 dCi 175 4WD | M9R868 | 04.2016- |
| RENAULT | KOLEOS II (HC_) 2.0 dCi 175 (HCAK) | M9R868 | 04.2016- |
| RENAULT | MASTER IV Bus BLUE DCI 150 | M9R670 | 06.2024- |
| RENAULT | MASTER IV Platform/Chassis BLUE DCI 130 | M9R670 | 06.2024- |
| RENAULT | MASTER IV Platform/Chassis BLUE DCI 150 | M9R670 | 06.2024- |
| RENAULT | MASTER IV Platform/Chassis BLUE DCI 170 | M9R670 | 06.2024- |
| RENAULT | MASTER IV Van (F8__) BLUE DCI 105 (F8M1) | M9R670 | 06.2024- |
| RENAULT | MASTER IV Van (F8__) BLUE DCI 130 (F8M2) | M9R670 | 06.2024- |
| RENAULT | MASTER IV Van (F8__) BLUE DCI 150 (F8M3) | M9R670 | 06.2024- |
| RENAULT | MASTER IV Van (F8__) BLUE DCI 170 (F8M4) | M9R670 | 06.2024- |
| RENAULT | TALISMAN Grandtour (KP_) 2.0 Blue dCi 160 (KPAM) | M9R650 | 01.2019-03.2022 |
| RENAULT | TALISMAN Grandtour (KP_) 2.0 Blue dCi 200 (KPAL) | M9R650 | 01.2019-03.2022 |
| RENAULT | TALISMAN (LP_) 2.0 Blue dCi 160 (LPAM) | M9R650 | 01.2019-03.2022 |
| RENAULT | TALISMAN (LP_) 2.0 Blue dCi 200 (LPAL) | M9R650 | 01.2019-03.2022 |
| RENAULT | TRAFIC III Bus (JG_) 2.0 dCi 145 (JGML) | M9R710 | 06.2019- |
| RENAULT | TRAFIC III Bus (JG_) 2.0 dCi 150 (JGMU) | M9R714 | 05.2021- |
| RENAULT | TRAFIC III Bus (JG_) 2.0 dCi 150 (JGMU) | M9R717 | 05.2021- |
| RENAULT | TRAFIC III Bus (JG_) 2.0 dCi 170 (JGMM, JGMV) | M9R710 | 06.2019- |
| RENAULT | TRAFIC III Bus (JG_) 2.0 dCi 170 (JGMM, JGMV) | M9R714 | 06.2019- |
| RENAULT | TRAFIC III Bus (JG_) 2.0 dCi 170 (JGMM, JGMV) | M9R717 | 06.2019- |
| RENAULT | TRAFIC III Van (FG_) 2.0 dCi 145 (FGML) | M9R710 | 06.2019- |
| RENAULT | TRAFIC III Van (FG_) 2.0 dCi 150 (FGMU) | M9R714 | 08.2021- |
| RENAULT | TRAFIC III Van (FG_) 2.0 dCi 150 (FGMU) | M9R717 | 08.2021- |
| RENAULT | TRAFIC III Van (FG_) 2.0 dCi 170 (FGMM, FGMV) | M9R710 | 06.2019- |
| RENAULT | TRAFIC III Van (FG_) 2.0 dCi 170 (FGMM, FGMV) | M9R717 | 06.2019- |
