Brand new AS-PL Alternator
PREMIUM LINE
Mitsubishi
MITSUBISHI
Price:
NZ$ 477.00 including GST
NZ$ 414.78 excluding GST
or four payments of $119.25
with
Learn More
Product Code:
S5643(MITSUBISHI)
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 0.90 kW |
| Length (L.1) | 183.00 mm |
| Mount Hole Center - Center (O.1) | 101.00 mm |
| Mount Hole Diameter (C.1) | 11.00 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 28.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 70.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | BALENO (FW, EW) 1.0 (A1K310) | K10C-T | 02.2016- |
| SUZUKI | IGNIS III (MF, FF) 1.2 AllGrip (ATK412) | K12C | 10.2016- |
| SUZUKI | IGNIS III (MF, FF) 1.2 (ATK412) | K12C | 10.2016- |
| SUZUKI | IGNIS III (MF, FF) 1.2 Hybrid AllGrip (ATK412) | K12C | 10.2016- |
| SUZUKI | IGNIS III (MF, FF) 1.2 Hybrid (ATK412, FF21S) | K12C | 10.2016- |
| SUZUKI | SWIFT V (AZ) 1.0 (A2L310) | K10C-T | 04.2017- |
| SUZUKI | SWIFT V (AZ) 1.2 (A2L412, ZC83S) | K12C | 04.2017- |
| SUZUKI | SWIFT V (AZ) 1.2 AllGrip (A2L412) | K12C | 04.2017- |
| SUZUKI | SWIFT V (AZ) 1.2 SHVS (A2L412) | K12CS | 04.2017- |
| SUZUKI | SWIFT V (AZ) 1.2 SHVS AllGrip (A2L412) | K12CS | 04.2017- |
| SUZUKI | SWIFT V (AZ) 1.4 Sport (A2L414, ZC33S) | K14C | 09.2017- |
| SUZUKI | SX4 S-CROSS (JY) 1.0 (AKK 310) | K10C-T | 08.2016- |
| SUZUKI | SX4 S-CROSS (JY) 1.0 AllGrip (AKK 310) | K10C-T | 08.2016- |
| SUZUKI | SX4 S-CROSS (JY) 1.4 T (AKK414) | K14C | 08.2016- |
| SUZUKI | SX4 S-CROSS (JY) 1.4 T AllGrip (AKK414) | K14C | 08.2016- |
| SUZUKI | SX4 S-CROSS (JY) 1.6 (AKK 416) | M16A | 08.2013- |
| SUZUKI | SX4 S-CROSS (JY) 1.6 (AKK416, YA22S) | M16A | 12.2013- |
| SUZUKI | SX4 S-CROSS (JY) 1.6 AllGrip (AKK 416) | M16A | 08.2013- |
| SUZUKI | SX4 S-CROSS (JY) 1.6 AllGrip (AKK416, YB22S) | M16A | 12.2013- |
| SUZUKI | VITARA (LY) 1.0 AllGrip (APK 310) | K10C-T | 10.2018- |
| SUZUKI | VITARA (LY) 1.0 (APK 310) | K10C-T | 10.2018- |
| SUZUKI | VITARA (LY) 1.4 T AllGrip (APK414) | K14C | 09.2015- |
| SUZUKI | VITARA (LY) 1.4 T (APK414) | K14C | 09.2015- |
| SUZUKI | VITARA (LY) 1.6 AllGrip (APK 416) | M16A | 02.2015- |
| SUZUKI | VITARA (LY) 1.6 AllGrip (APK416, YE21S) | M16A | 05.2015- |
| SUZUKI | VITARA (LY) 1.6 (APK 416) | M16A | 02.2015- |
| SUZUKI | VITARA (LY) 1.6 (APK416, YD21S) | M16A | 05.2015- |
