Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 645.08 including GST
NZ$ 560.94 excluding GST
or four payments of $161.27
with
Learn More
Product Code:
S6794S
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 2.70 kW |
| Length (L.1) | 300.00 mm |
| Mount Hole Center - Center (O.1) | 134.00 mm |
| Mount Hole Diameter (C.1) | M12x1.25 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 15.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| METROCAB | TAXI 2.4 TD | 2L-T | 01.2001-05.2006 |
| TOYOTA | DYNA 100 Platform/Chassis (LY1_, YY1_) 2.4 D (LY100_, LY100R) | 2L | 05.1995-07.2001 |
| TOYOTA | DYNA 150 Platform/Chassis (LY_) 2.8 D (LY211) | 3L | 05.1995-08.1998 |
| TOYOTA | DYNA 150 Platform/Chassis (LY_) 2.8 D (LY61_) | 3L | 08.1988-05.1995 |
| TOYOTA | DYNA 150 Platform/Chassis (LY_) 3.0 D (LY102, LY112, LY122) | 5L | 09.1998-07.2001 |
| TOYOTA | DYNA Platform/Chassis (LH8_) 2.4 D (LH80_, LH80R) | 2L | 08.1987-04.1995 |
| TOYOTA | HIACE III Bus (_H5_, _H6_, _H7_, _H8_, _H9_) 2.4 D 4WD (LH56, LH66) | 2L | 01.1987-08.1989 |
| TOYOTA | HIACE III Bus (_H5_, _H6_, _H7_, _H8_, _H9_) 2.4 D (LH51, LH61, LH66) | 2L | 04.1984-08.1989 |
| TOYOTA | HIACE III Van (_H5_, _H6_, _H7_, _H8_, _H9_) 2.4 D (LH61, LH51) | 2L | 12.1982-11.1989 |
| TOYOTA | HIACE II Van (_H11, _H2_, _H3_, _H4_) 2.2 D (LH20, LH30) | L | 01.1979-03.1983 |
| TOYOTA | HIACE IV Bus (_H1_) 2.4 D 4WD (LH51_, LH61_, LH66_, LH71_, LH51R, LH61R,... | 2L | 08.1987-08.1995 |
| TOYOTA | HIACE IV Bus (_H1_) 2.4 D (LH100, LH110, LH104, LH114) | 2L | 08.1989-12.2004 |
| TOYOTA | HIACE IV Bus (_H1_) 2.4 D (LH102) | 2L | 08.1989-08.1995 |
| TOYOTA | HIACE IV Bus (__H1_, __H2_) 2.4 D (LXH12) | 2L | 08.1995-08.2001 |
| TOYOTA | HIACE IV Bus (__H1_, __H2_) 2.4 D (LXH12, LXH22) | 2L | 08.1995-08.2001 |
| TOYOTA | HIACE IV Bus (__H1_, __H2_) 2.4 TD 4WD (LXH18, LXH28) | 2L-T | 08.1995-08.2001 |
| TOYOTA | HIACE IV Bus (__H1_, __H2_) 2.4 TD (LXH12, LXH22) | 2L-T | 08.1995-08.2001 |
| TOYOTA | HIACE IV Van (_H1_) 2.4 D 4WD | 2L | 09.1989-08.1995 |
| TOYOTA | HIACE IV Van (_H1_) 2.4 D 4WD (LH108, LH118) | 2L | 08.1989-07.1999 |
| TOYOTA | HIACE IV Van (_H1_) 2.4 D (LH102, LH104, LH112) | 2L | 09.1989-08.1995 |
| TOYOTA | HIACE IV Van (_H1_) 2.4 D (LH112) | 2L | 08.1989-08.2004 |
| TOYOTA | HIACE IV Van (__H1_, __H2_) 2.4 D (LXH12, LXH22) | 2L | 08.1995-08.2001 |
| TOYOTA | HIACE IV Van (__H1_, __H2_) 2.4 D (LXH12, LXH22) | 2L | 08.1995-08.2001 |
| TOYOTA | HIACE IV Van (__H1_, __H2_) 2.4 TD 4WD (LXH18, LXH28) | 2L-T | 08.1995-08.2001 |
| TOYOTA | HIACE IV Van (__H1_, __H2_) 2.4 TD (LXH12, LXH22) | 2L-T | 08.1995-08.2001 |
| TOYOTA | HILUX IV Pickup (_N5_, _N6_) 2.4 D 4WD (LN65) | 2L | 08.1983-07.1988 |
| TOYOTA | HILUX VI Pickup (_N1_) 2.4 D (LN145, LN150) | 2L | 08.1997-07.2005 |
| TOYOTA | HILUX VI Pickup (_N1_) 2.4 D (LN150, LN145) | 2L | 08.1997-04.2005 |
| TOYOTA | HILUX VI Pickup (_N1_) 2.4 TD 4WD (LN165_, LN170_, LN190_, LN165, LN165H,... | 2L-T | 08.1998-01.2002 |
| TOYOTA | HILUX VI Pickup (_N1_) 2.4 TD (LN190) | 2L-T | 08.1997-07.2001 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D 4WD (LN105_, LN108_, LN110_) | 2L | 09.1994-07.1997 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D 4WD (LN105, LN110) | 2L | 09.1988-08.1997 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D 4WD (LN110_, LN110R) | 2L | 01.1994-12.1997 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D (LN5_, LN85, LN90) | 2L | 10.1988-07.1997 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D (LN85_, LN110, LN90) | 2L | 09.1988-08.1997 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D (LN85, LN90) | 2L | 10.1991-07.1997 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 D (LN90_, LN90R) | 2L | 03.1995-08.1997 |
| TOYOTA | LAND CRUISER Hardtop (_J7_) 2.4 TD (LJ70_, LJ70R) | 2L-T | 07.1990-05.1996 |
| TOYOTA | LAND CRUISER (_J7_, _JL7_) 2.4 D (LJ70_, LJ70R) | 2L | 11.1984-10.1985 |
| TOYOTA | LAND CRUISER (_J7_, _JL7_) 2.4 TD (LJ70) | 2L-T | 01.1990-05.1993 |
| TOYOTA | LAND CRUISER (_J7_, _JL7_) 2.4 TD (LJ70_, LJ73_, LJ70RV) | 2L-T | 10.1985-05.1990 |
| VW | TARO 2.4 D | 2L | 06.1989-03.1997 |
| VW | TARO 2.4 D | 2L | 07.1994-03.1997 |
| VW | TARO 2.4 D | 2L | 09.1991-07.1994 |
| VW | TARO 2.4 D 4x4 | 2L | 04.1989-03.1997 |
| VW | TARO 2.4 D 4x4 | 2L | 07.1994-03.1997 |
