Brand new AS-PL Alternator
PREMIUM LINE
SEG Automotive
BOSCH
Price:
NZ$ 1,340.74 including GST
NZ$ 1,165.86 excluding GST
or four payments of $335.19
with
Learn More
Product Code:
S01241(SEG)
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 223.00 mm |
| Mount Hole Center - Center (O.1) | 105.00 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 21.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | HIACE IV Bus (_H1_) 2.4 4WD (RZH103_, RZH109_, RZH113_, RZH115_, RZH103R,... | 2RZ-E | 08.1989-07.1995 |
| TOYOTA | HIACE IV Bus (_H1_) 2.4 (RZH103, RZH183) | 2RZ-E | 08.1989-08.2003 |
| TOYOTA | HIACE IV Bus (__H1_, __H2_) 2.4 (RCH12, RCH22) | 2RZ-E | 08.1995-04.1998 |
| TOYOTA | HIACE IV Van (_H1_) 2.0 (RZH102, RZH112) | 1RZ | 02.1990-08.2004 |
| TOYOTA | HIACE IV Van (_H1_) 2.4 4WD (RCH103_, RCH113_, RCH103R, RCH113R) | 2RZ-E | 08.1989-08.1995 |
| TOYOTA | HIACE IV Van (_H1_) 2.4 (RZH10) | 2RZ-E | 08.1989-08.1995 |
| TOYOTA | HILUX V Pickup (_N8_, _N9_, _N10_, _N11_) 2.4 EFI 4WD (RN106_, RN110_, RN106R, RN110R) | 22RE | 01.1989-07.1997 |
| TOYOTA | MR2 III (ZZW3_) 1.8 16V VT-i (ZZW30) | 1ZZ-FE | 10.1999-06.2007 |
View your shopping basket or Browse other items in Starter Motors.
