Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 414.35 including GST
NZ$ 360.30 excluding GST
or four payments of $103.59
with
Learn More
UOM:
each
Product Code:
A4174S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 105 A |
| Bottom Mounting Foot Width (B) | 21.50 mm |
| Diameter (D.1) | 12.00 mm |
| Diameter (D.2) | 11.00 mm |
| Diameter (D.3) | 12.00 mm |
| Length (L.1) | 207.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54.00 mm |
| Plug Code | PL_9104 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.2) | 49.00 mm |
| Pulley to Mount Distance (A) | 44.00 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 147 (937_) 2.0 16V T.SPARK (937.AXA1, 937.AXC1, 937.BXC1) | AR32310 | 01.2001-03.2010 |
| FIAT | STILO (192_) 1.8 16V (192AXC1A, 192BXC1A) | 192A4.000 | 10.2001-04.2007 |
| FIAT | STILO Multi Wagon (192_) 1.8 16V | 192A4.000 | 01.2003-08.2008 |
Reference Information
| 078ST58 | STARTCAR |
| 20040488OV | ITAB AUTOMOTIVE |
| 2181481102 | DRI |
| 28-8764 | ELSTOCK |
| 301223RI | KUHNER |
| 301223RID | KUHNER |
| 3110089 | HENKEL PARTS |
| 3110090 | HENKEL PARTS |
| 3110091 | HENKEL PARTS |
| 40934 | CEVAM |
| 46791695 | FIAT |
| 58078 | EAI |
| 60817008 | FIAT |
| 63321841 | MAGNETI MARELLI |
| 9040641 | FRIESEN |
| ADN488 | AUTOTEAM |
| AL04658 | TMI |
| ANM100516 | ANDEL |
| FI8161 | SNRA |
| LRA04655 | LUCAS |
| LRA4655 | LUCAS |
| STX102316R | STARDAX |
| UD103567A | AS-PL |
| WAL02974 | WALKER |
