Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 895.70 including GST
NZ$ 778.87 excluding GST
or four payments of $223.93
with
Learn More
UOM:
each
Product Code:
A3946S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 180 A |
| Diameter (D.1) | 9.50 mm |
| Diameter (D.2) | 9.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 178.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 37.00 mm |
| Pad mount thickness (E.1) | 65.00 mm |
| Pad mount thickness (E.2) | 65.00 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.2) | 52.50 mm |
| Pulley to Mount Distance (A) | 41.00 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | NX II (_A2_, _H2_) 350 All-wheel Drive (TAZA25) | T24A-FTS | 09.2021- |
| LEXUS | RX (_LA1_, _LH1_) 350 (TALA10) | T24A-FTS | 01.2023- |
| LEXUS | TX (TAU_, GYU_) 350 AWD (TAUA15L) | T24A-FTS | 09.2023- |
| LEXUS | TX (TAU_, GYU_) 350 (TAUA10L) | T24A-FTS | 09.2023- |
| TOYOTA | GRAND HIGHLANDER (ASH_) 2.4 4WD (TASA15L) | T24A-FTS | 08.2023- |
| TOYOTA | GRAND HIGHLANDER (ASH_) 2.4 (TASA10L) | T24A-FTS | 08.2023- |
| TOYOTA | HIGHLANDER (GSU7_, AXUH7_, TXUA7_) 2.4 VVTi AWD (TXUA75R) | T24A-FTS | 10.2022- |
| TOYOTA | HIGHLANDER (GSU7_, AXUH7_, TXUA7_) 2.4 VVTi (TXUA70R) | T24A-FTS | 10.2022- |
Reference Information
| 0986UR6616 | BOSCH |
| 22335N | WAI |
| 27060-0W020 | TOYOTA |
| 27060-0W020-A | TOYOTA |
| FGN17S029 | VALEO |
| UD104994A | AS-PL |
