Brand new AS-PL Alternator

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

NIKKO

Price:

NZ$ 1,798.62 including GST

NZ$ 1,564.02 excluding GST

or four payments of $449.66 with
Learn More

Product Code:

A9653S

Quantity In Stock Nationally

No stock in NZ currently

Availability:

This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**

Amp	90 A
Bottom Mounting Foot Width (B)	15.00 mm
Diameter (D.1)	M12x1.5 mm
Diameter (D.2)	13.00 mm
Diameter (D.3)	13.00 mm
Length (L.1)	259.00 mm
Mount Inside Length or Pad Mount C-C (C)	109.00 mm
Plug Code	PL_9104
Pulley Grooves	2 qty
Pulley Groove Width (W.1)	12.00 mm
Pulley Outside Diameter (O.D.1)	87.00 mm
Pulley Outside Diameter (O.D.2)	60.00 mm
Pulley to Mount Distance (A)	57.00 mm
Pulley Type	Solid
Voltage	24 V

Make	Model	Type	Year
KOMATSU	D65WX-15E0 8.3	SAA6D114E-3	01.2004-12.2010
KOMATSU	GD655-5 6.7	SAA6D107E-1	01.2012-12.2018
KOMATSU	HD785-5 30.5	SA12V140	01.1999-12.2007
KOMATSU	WA380-5 8.3	SAA6D114E-2	01.2001-12.2008
KOMATSU	WA380-6 6.7	SAA6D107E-1	01.2006-12.2015
KOMATSU	WA470-5 11.0	SAA6D125E-3	01.2001-12.2006
KOMATSU	WA480-5 11.0	SAA6D125E-3	01.2002-12.2007

A9653S - Brand new AS-PL Alternator
