Brand new AS-PL Alternator
PREMIUM LINE
AS-PL
MITSUBISHI
Price:
NZ$ 304.22 including GST
NZ$ 264.54 excluding GST
or four payments of $76.06
with
Learn More
Product Code:
S5234PR
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 1.20 kW |
| Length (L.1) | 182.00 mm |
| Mount Hole Center - Center (O.1) | 102.00 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 8 qty |
| Pinion at Rest (B) | 28.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 70.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | SEDICI (189_) 1.6 16V | M16A | 06.2006-10.2014 |
| FIAT | SEDICI (189_) 1.6 16V | M16A | 06.2006-10.2014 |
| FIAT | SEDICI (189_) 1.6 16V 4x4 | M16A | 06.2006-10.2014 |
| FIAT | SEDICI (189_) 1.6 16V 4x4 | M16A | 06.2006-10.2014 |
| SUBARU | JUSTY III (G3X) 1.3 AWD (G3X413) | M13A | 09.2003- |
| SUBARU | JUSTY III (G3X) 1.5 AWD (G3X413) | M15A | 09.2003- |
| SUZUKI | GRAND VITARA II (JT, TE, TD) 1.6 All-wheel Drive (JB416) | M16A | 04.2005-02.2015 |
| SUZUKI | GRAND VITARA II (JT, TE, TD) 1.6 All-wheel Drive (TA74, JB416) | M16A | 09.2005-02.2015 |
| SUZUKI | GRAND VITARA II (JT, TE, TD) 1.6 (JB416) | M16A | 10.2005- |
| SUZUKI | IGNIS I (FH) 1.3 4WD (RG413) | M13A | 10.2000-09.2003 |
| SUZUKI | IGNIS I (FH) 1.3 (HV51, HX51, RG413) | M13A | 10.2000-09.2003 |
| SUZUKI | IGNIS I (FH) 1.5 Sport (RG415) | M15A | 12.2003-12.2005 |
| SUZUKI | IGNIS II (MH) 1.3 4x4 (RM413) | M13A | 09.2003- |
| SUZUKI | IGNIS II (MH) 1.3 (RM413) | M13A | 09.2003- |
| SUZUKI | IGNIS II (MH) 1.5 4x4 (RM415) | M15A | 09.2003- |
| SUZUKI | IGNIS II (MH) 1.5 (RM415) | M15A | 09.2003- |
| SUZUKI | JIMNY Closed Off-Road Vehicle (SN) 1.3 16V 4WD (SN413) | M13A | 02.2001- |
| SUZUKI | JIMNY Closed Off-Road Vehicle (SN) 1.3 16V 4x4 (SN413) | M13A | 08.2005- |
| SUZUKI | JIMNY Closed Off-Road Vehicle (SN) 1.3 16V (SN413) | M13A | 02.2001- |
| SUZUKI | JIMNY Closed Off-Road Vehicle (SN) 1.3 4WD (SN413) | M13A | 05.2014- |
| SUZUKI | JIMNY Closed Off-Road Vehicle (SN) 1.3 (SN413) | M13A | 08.2004- |
| SUZUKI | JIMNY Open Off-Road Vehicle (SN) 1.3 4WD (SN413) | M13A | 03.2013- |
| SUZUKI | JIMNY Open Off-Road Vehicle (SN) 1.3 (SN413) | M13A | 08.2004- |
| SUZUKI | LIANA (ER, RH_) 1.3 (RH 413) | M13A | 03.2002- |
| SUZUKI | LIANA (ER, RH_) 1.6 4WD (RH416) | M16A | 01.2005-12.2007 |
| SUZUKI | LIANA (ER, RH_) 1.6 4WD (RH416) | M16A | 03.2002- |
| SUZUKI | LIANA (ER, RH_) 1.6 4WD (RH416) | M16A | 04.2002- |
| SUZUKI | LIANA (ER, RH_) 1.6 i (RH416) | M16A | 04.2002- |
| SUZUKI | LIANA (ER, RH_) 1.6 (RH416) | M16A | 01.2005- |
| SUZUKI | LIANA (ER, RH_) 1.6 (RH416) | M16A | 03.2002- |
| SUZUKI | LIANA Hatchback 1.3 | M13A | 07.2001-12.2007 |
| SUZUKI | LIANA Hatchback 1.6 | M16A | 01.2005-08.2007 |
| SUZUKI | LIANA Hatchback 1.6 4WD | M16A | 01.2005-12.2007 |
| SUZUKI | LIANA Hatchback 1.6 4WD | M16A | 04.2002-12.2007 |
| SUZUKI | LIANA Hatchback 1.6 4WD | M16A | 07.2001-12.2007 |
| SUZUKI | LIANA Hatchback 1.6 i (RH416) | M16A | 04.2002-12.2007 |
| SUZUKI | LIANA Hatchback 1.6 (RH416) | M16A | 07.2001-12.2007 |
| SUZUKI | SWIFT III (MZ, EZ) 1.3 4x4 (RS 413, ZD11S) | M13A | 02.2005- |
| SUZUKI | SWIFT III (MZ, EZ) 1.3 4x4 (RS413, ZD11S) | M13A | 01.2006- |
| SUZUKI | SWIFT III (MZ, EZ) 1.3 LPG (RS 413) | M13A | 09.2008-12.2010 |
| SUZUKI | SWIFT III (MZ, EZ) 1.3 (RS413, ZC11S) | M13A | 02.2005- |
| SUZUKI | SWIFT III (MZ, EZ) 1.5 (RS415, ZC21S) | M15A | 02.2005- |
| SUZUKI | SWIFT III (MZ, EZ) 1.6 (RS416, RR 416, ZC31S) | M16A | 05.2006- |
| SUZUKI | SWIFT IV (FZ, NZ) 1.6 (AZG416, AZH416, RS416, ZC32S, ZA32S) | M16A | 01.2012- |
| SUZUKI | SX4 (EY, GY) 1.5 (RW 415) | M15A | 06.2006-07.2010 |
| SUZUKI | SX4 (EY, GY) 1.5 VVTi (YA11S) | M15A | 07.2007-12.2015 |
| SUZUKI | SX4 (EY, GY) 1.5 VVT (RW415, YA11S) | M15A | 07.2010- |
| SUZUKI | SX4 (EY, GY) 1.6 LPG | M16A | 06.2006-12.2012 |
| SUZUKI | SX4 (EY, GY) 1.6 VVT | M16A | 11.2010-12.2015 |
| SUZUKI | SX4 (EY, GY) 1.6 VVT 4x4 (RW416) | M16A | 06.2006- |
| SUZUKI | SX4 (EY, GY) 1.6 VVT 4x4 (RW416) | M16A | 07.2009- |
| SUZUKI | SX4 (EY, GY) 1.6 VVT 4x4 (RW416) | M16A | 07.2009- |
| SUZUKI | SX4 (EY, GY) 1.6 VVT (RW416, YA21S) | M16A | 06.2006- |
| SUZUKI | SX4 (EY, GY) 1.6 VVT (RW416, YA21S) | M16A | 07.2009- |
| SUZUKI | SX4 Saloon (GY, RW) 1.6 (RW416) | M16A | 10.2007- |
| SUZUKI | SX4 Saloon (GY, RW) 1.6 (RW416) | M16A | 10.2007- |
| SUZUKI | WAGON R+ (MA) 1.3 4WD (RB413) | M13A | 09.2003- |
| SUZUKI | WAGON R+ (MA) 1.3 (RB413) | M13A | 09.2003-08.2006 |
