Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 694.35 including GST
NZ$ 603.78 excluding GST
or four payments of $173.59
with
Learn More
Product Code:
A3922S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 140 A |
| Diameter (D.1) | 9.00 mm |
| Diameter (D.2) | 9.00 mm |
| Diameter (D.3) | 8.50 mm |
| Diameter (D.4) | 8.50 mm |
| Length (L.1) | 198.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56.00 mm |
| Pad mount thickness (E.1) | 70.00 mm |
| Pad mount thickness (E.2) | 70.00 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.2) | 56.00 mm |
| Pulley to Mount Distance (A) | 31.00 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A1 Sportback (GBA) 40 TFSI | DNND | 04.2021- |
| AUDI | A3 Limousine (8YS, 8YM) 40 TFSI quattro | DNNA | 07.2021- |
| AUDI | A3 Limousine (8YS, 8YM) S3 quattro | DNFB | 06.2020- |
| AUDI | A3 Limousine (8YS, 8YM) S3 quattro | DNFF | 02.2024- |
| AUDI | A3 Limousine (8YS, 8YM) S3 quattro | DSFA | 06.2020- |
| AUDI | A3 Limousine (8YS, 8YM) S3 quattro | DSFD | 02.2024- |
| AUDI | A3 Sportback (8YA, 8YF) 40 TFSI quattro | DNNA | 07.2021- |
| AUDI | A3 Sportback (8YA, 8YF) S3 quattro | DNFB | 06.2020- |
| AUDI | A3 Sportback (8YA, 8YF) S3 quattro | DNFF | 02.2024- |
| AUDI | A3 Sportback (8YA, 8YF) S3 quattro | DSFD | 02.2024- |
| AUDI | Q2 (GAB, GAG) 2.0 TFSI quattro | CZPB | 05.2017- |
| AUDI | Q2 (GAB, GAG) 2.0 TFSI quattro | DKZA | 05.2017- |
| AUDI | Q2 (GAB, GAG) 40 TFSI quattro | DKZA | 09.2018- |
| AUDI | Q2 (GAB, GAG) 40 TFSI quattro | DNNA | 04.2021- |
| AUDI | Q2 (GAB, GAG) 40 TFSI quattro | DNNA | 09.2018- |
| AUDI | Q2 (GAB, GAG) SQ2 TFSI quattro | DNFC | 08.2018- |
| AUDI | Q2 (GAB, GAG) SQ2 TFSI quattro | DNUE | 08.2018- |
| AUDI | Q3 (F3B) 40 TFSI quattro | DKTC | 07.2018- |
| AUDI | Q3 (F3B) 40 TFSI quattro | DNNA | 04.2021- |
| AUDI | Q3 (F3B) 40 TFSI quattro | DNNA | 07.2018- |
| AUDI | Q3 (F3B) 45 TFSI quattro | DNPA | 01.2021- |
| AUDI | Q3 Sportback (F3N) 40 TFSI quattro | DKTC | 11.2019- |
| AUDI | Q3 Sportback (F3N) 40 TFSI quattro | DNNA | 04.2021- |
| AUDI | Q3 Sportback (F3N) 40 TFSI quattro | DNNA | 11.2019- |
| AUDI | Q3 Sportback (F3N) 45 TFSI quattro | DNPA | 01.2021- |
| CUPRA | ATECA (KH7, KHP, KBP) 2.0 TSI 4Drive | DNFC | 09.2018- |
| CUPRA | ATECA (KH7, KHP, KBP) 2.0 TSI 4Drive | DNNA | 06.2023- |
| CUPRA | ATECA (KH7, KHP, KBP) 2.0 TSI 4Drive | DNUE | 09.2018- |
| CUPRA | FORMENTOR (KM7, KMP) 2.0 TSI | CZPB | 01.2021- |
| CUPRA | FORMENTOR (KM7, KMP) 2.0 TSI | DNPA | 03.2021- |
| CUPRA | FORMENTOR (KM7, KMP) 2.0 TSI 4Drive | DNFB | 07.2020- |
| CUPRA | FORMENTOR (KM7, KMP) 2.0 TSI 4Drive | DNNA | 08.2020- |
| CUPRA | LEON (KL1, KU1, KUG) 2.0 TSI | DNFC | 06.2021- |
| CUPRA | LEON (KL1, KU1, KUG) 2.0 TSI | DNNA | 09.2022- |
| CUPRA | LEON (KL1, KU1, KUG) 2.0 TSI | DNPA | 06.2021- |
| CUPRA | LEON Sportstourer (KL8, KU8, KUD) 2.0 TSI | DNFC | 06.2021- |
| CUPRA | LEON Sportstourer (KL8, KU8, KUD) 2.0 TSI | DNNA | 09.2022- |
| CUPRA | LEON Sportstourer (KL8, KU8, KUD) 2.0 TSI | DNPA | 06.2021- |
| CUPRA | LEON Sportstourer (KL8, KU8, KUD) 2.0 TSI 4Drive | DNFB | 06.2021- |
| CUPRA | LEON Sportstourer (KL8, KU8, KUD) 2.0 VZ 4Drive | DNFF | 07.2024- |
| SEAT | ATECA (KH7, KHP) 2.0 TSI 4Drive | CZPB | 05.2017- |
| SEAT | ATECA (KH7, KHP) 2.0 TSI 4Drive | DKZA | 05.2017- |
| SEAT | ATECA (KH7, KHP) 2.0 TSI 4Drive | DNNA | 05.2017- |
| SEAT | LEON (KL1, KLG) 2.0 TFSI | CZPB | 03.2021- |
| SEAT | LEON (KL1, KLG) 2.0 TFSI | DNNA | 03.2021- |
| SEAT | LEON Sportstourer (KL8, KLD) 2.0 TFSI | DNNA | 03.2021- |
| SEAT | TARRACO (KN2) 2.0 TFSI 4Drive | DNPA | 01.2021- |
| SEAT | TARRACO (KN2) 2.0 TSI 4Drive | DKZA | 11.2018- |
| SEAT | TARRACO (KN2) 2.0 TSI 4Drive | DNNA | 11.2018- |
| SEAT | TARRACO (KN2) 2.0 TSI 4Drive | DNNA | 11.2020-05.2024 |
| SKODA | KAROQ (NU7, ND7) 2.0 TSI 4x4 | DKZA | 04.2019- |
| SKODA | KAROQ (NU7, ND7) 2.0 TSI 4x4 | DNNA | 04.2019- |
| SKODA | KODIAQ I (NS6, NS7, NV7) 2.0 RS 4x4 | DNPA | 06.2021- |
| SKODA | OCTAVIA IV Combi (NX5, PV5) 2.0 TSI 4x4 | CZPB | 09.2020- |
| SKODA | OCTAVIA IV Combi (NX5, PV5) 2.0 TSI 4x4 | DNNA | 09.2020- |
| SKODA | OCTAVIA IV Combi (NX5, PV5) 2.0 TSI RS | DLBA | 03.2020- |
| SKODA | OCTAVIA IV Combi (NX5, PV5) 2.0 TSI RS | DNPA | 03.2020- |
| SKODA | OCTAVIA IV (NX3, NN3, PV3) 2.0 TSI 4x4 | DNNA | 07.2020- |
| SKODA | OCTAVIA IV (NX3, NN3, PV3) 2.0 TSI RS | DLBA | 03.2020- |
| SKODA | OCTAVIA IV (NX3, NN3, PV3) 2.0 TSI RS | DNPA | 03.2020- |
| VW | ARTEON (3H7, 3H8) 2.0 TSI | CZPB | 05.2017- |
| VW | ARTEON (3H7, 3H8) 2.0 TSI | DKZA | 05.2017- |
| VW | ARTEON (3H7, 3H8) 2.0 TSI | DNNA | 05.2017- |
| VW | ARTEON (3H7, 3H8) 2.0 TSI | DNNA | 11.2020-12.2024 |
| VW | ARTEON (3H7, 3H8) 2.0 TSI R | DNFG | 11.2020- |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSi | CZPB | 09.2020- |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSi | DKZA | 09.2020- |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSi | DNNA | 06.2020-12.2024 |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSi | DNNA | 09.2020- |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSi | DUNA | 06.2020-12.2024 |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSi | DUNA | 09.2020- |
| VW | ARTEON SHOOTING BRAKE (3H9) 2.0 TSI R | DNFG | 11.2020- |
| VW | GOLF ALLTRACK VIII (CG5) 2.0 TSI 4motion | DNNA | 03.2021- |
| VW | GOLF VIII (CD1, DA1) 2.0 GTI | DLBA | 08.2020- |
| VW | GOLF VIII (CD1, DA1) 2.0 GTI | DNPA | 08.2020- |
| VW | GOLF VIII (CD1, DA1) 2.0 GTI | DNPD | 06.2024- |
| VW | GOLF VIII (CD1, DA1) 2.0 GTI | DRNA | 08.2020- |
| VW | GOLF VIII (CD1, DA1) 2.0 GTI Clubsport | DNFC | 10.2020- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI | DNNA | 06.2021- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI 4motion | DNNA | 06.2021- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI 4motion | DNNE | 12.2024- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI R 4motion | DNFF | 07.2022- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI R 4motion | DNFG | 09.2020- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI R 4motion | DSFE | 09.2020- |
| VW | GOLF VIII (CD1, DA1) 2.0 TSI R 4motion | DSFF | 09.2020- |
| VW | GOLF VIII Variant (CG5, DB5) 2.0 TSI | DNNA | 06.2021- |
| VW | GOLF VIII Variant (CG5, DB5) 2.0 TSI 4motion | DNNA | 06.2021- |
| VW | GOLF VIII Variant (CG5, DB5) 2.0 TSI 4motion | DNNE | 12.2024- |
| VW | GOLF VIII Variant (CG5, DB5) 2.0 TSI R 4motion | DNFF | 06.2024- |
| VW | GOLF VIII Variant (CG5, DB5) 2.0 TSI R 4motion | DNFG | 06.2021- |
| VW | POLO VI (AW1, BZ1, AE1) GTI | DNND | 04.2021- |
| VW | TIGUAN (AD1, AX1) 2.0 TSI 4motion | DNPA | 01.2021- |
| VW | TIGUAN (AD1, AX1) 2.0 TSI R 4motion | DNFG | 11.2020- |
| VW | TIGUAN (AD1, AX1) 2.0 TSI R 4motion | DSFE | 11.2020- |
| VW | TIGUAN ALLSPACE (BW2, BJ2) 2.0 TSI 4motion | DNLA | 09.2018- |
| VW | TIGUAN ALLSPACE (BW2, BJ2) 2.0 TSI 4motion | DNNA | 09.2018- |
| VW | TIGUAN ALLSPACE (BW2, BJ2) 2.0 TSI 4motion | DNPA | 09.2020- |
Reference Information
| 06K903026C | VW |
| 0986UR6578 | BOSCH |
| 20010B21OV | ITAB AUTOMOTIVE |
| 2010112BOE | REAL |
| 2010B21.1 | SANDO |
| 2115911402 | DRI |
| 305.950.140.000 | WAI |
| 305.950.140.500 | WAI |
| 40831 | CEVAM |
| 443343 | VALEO |
| 461ST58 | STARTCAR |
| 556713RIS | KUHNER |
| 556713RIV | KUHNER |
| 58461 | EAI |
| 831029025 | TRISCAN |
| 9092023 | FRIESEN |
| AL04579 | TMI |
| ALT12B210 | SIOM |
| ANM100375 | ANDEL |
| AZMT-49-036-1539 | A.Z. MEISTERTEILE |
| CAL10B21GS | CASCO |
| STX102297R | STARDAX |
| TG14LLD106 | VALEO |
| UD104780A | AS-PL |
| VW8166 | SNRA |
| WAL01681 | WALKER |
