Brand new AS-PL Alternator
PREMIUM LINE
AS-PL
HITACHI
Price:
NZ$ 400.99 including GST
NZ$ 348.69 excluding GST
or four payments of $100.25
with
Learn More
UOM:
each
Product Code:
S2041PR
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 2.30 kW |
| Length (L.1) | 230.00 mm |
| Mount Hole Center - Center (O.1) | 120.00 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 21.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 95.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAEWOO | SOLAR 55-V | 4TNV94 | 01.1998-12.2003 |
| DAEWOO | SOLAR 55-V PLUS | 4TNV94 | 01.2003-12.2004 |
| DAEWOO | SOLAR 55W-V | 4TNE94 | 01.2003-12.2005 |
| DOOSAN | CD 20G PLUS | 4TNE98 | 01.2017-12.2023 |
| DOOSAN | CD 25G PLUS | 4TNE98 | 01.2017-12.2023 |
| DOOSAN | CD 30G PLUS | 4TNE98 | 01.2017-12.2023 |
| DOOSAN | D 20G | 4TNE98 | 01.2008-12.2017 |
| DOOSAN | D 20G PLUS | 4TNE94L | 01.2017-12.2023 |
| DOOSAN | D 20G PLUS | 4TNE98 | 01.2008-12.2017 |
| DOOSAN | D 20NX PLUS | 4TNE94L | 01.2019-12.2024 |
| DOOSAN | D 20NX PLUS | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 20NX PREMIUM | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 20S-5 | 4TNE94L | 01.2015-12.2021 |
| DOOSAN | D 20S-5 | 4TNE98 | 01.2007-12.2017 |
| DOOSAN | D 20S-7 | 4TNE94L | 01.2017-12.2021 |
| DOOSAN | D 25G | 4TNE98 | 01.2008-12.2017 |
| DOOSAN | D 25G PLUS | 4TNE94L | 01.2017-12.2023 |
| DOOSAN | D 25G PLUS | 4TNE98 | 01.2008-12.2017 |
| DOOSAN | D 25NX PLUS | 4TNE94L | 01.2019-12.2024 |
| DOOSAN | D 25NX PLUS | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 25NX PREMIUM | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 25S-5 | 4TNE94L | 01.2015-12.2021 |
| DOOSAN | D 25S-5 | 4TNE98 | 01.2007-12.2017 |
| DOOSAN | D 25S-5 | 4TNV98 | 01.2007-12.2017 |
| DOOSAN | D 25S-7 | 4TNE94L | 01.2017-12.2021 |
| DOOSAN | D 30G | 4TNE98 | 01.2008-12.2017 |
| DOOSAN | D 30G | 4TNV98 | 01.2017-12.2023 |
| DOOSAN | D 30G PLUS | 4TNE94L | 01.2017-12.2023 |
| DOOSAN | D 30G PLUS | 4TNE98 | 01.2008-12.2017 |
| DOOSAN | D 30NX PLUS | 4TNE94L | 01.2019-12.2024 |
| DOOSAN | D 30NX PLUS | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 30NX PREMIUM | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 30S-5 | 4TNE94L | 01.2015-12.2021 |
| DOOSAN | D 30S-5 | 4TNE98 | 01.2007-12.2017 |
| DOOSAN | D 30S-5 | 4TNV98 | 01.2007-12.2017 |
| DOOSAN | D 30S-7 | 4TNE94L | 01.2017-12.2021 |
| DOOSAN | D 33G | 4TNE98 | 01.2017-12.2023 |
| DOOSAN | D 33NX PLUS | 4TNE94L | 01.2019-12.2024 |
| DOOSAN | D 33NX PLUS | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 33NX PREMIUM | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 33S-5 | 4TNE94L | 01.2015-12.2021 |
| DOOSAN | D 33S-5 | 4TNE98 | 01.2007-12.2017 |
| DOOSAN | D 33S-7 | 4TNE94L | 01.2017-12.2021 |
| DOOSAN | D 35C-5 | 4TNE94L | 01.2015-12.2021 |
| DOOSAN | D 35C-5 | 4TNE98 | 01.2007-12.2017 |
| DOOSAN | D 35C-7 | 4TNE94L | 01.2017-12.2021 |
| DOOSAN | D 35G | 4TNE98 | 01.2017-12.2023 |
| DOOSAN | D 35NX PLUS | 4TNE94L | 01.2019-12.2024 |
| DOOSAN | D 35NX PLUS | 4TNE98 | 01.2019-12.2024 |
| DOOSAN | D 35NX PREMIUM | 4TNE98 | 01.2019-12.2024 |
| JOHN DEERE | H 304H | 4TNE98 | 01.2000-12.2005 |
| KOMATSU | FD 20-14 | 4D94E | 01.2000-12.2005 |
| KOMATSU | FD 20-17 | 4D94LE | 01.2006-12.2021 |
| KOMATSU | FD 25-14 | 4D94E | 01.2000-12.2005 |
| KOMATSU | FD 25-17 | 4D94LE | 01.2006-12.2021 |
| KOMATSU | FD 25H-17 | 4D98E | 01.2006-12.2021 |
| KOMATSU | FD 30-14 | 4D94E | 01.2000-12.2005 |
| KOMATSU | FD 30-17 | 4D94LE | 01.2006-12.2021 |
| KOMATSU | FD 30H-17 | 4D98E | 01.2006-12.2021 |
| KOMATSU | FD 35A-17 | 4D98E | 01.2006-12.2021 |
| KOMATSU | PC 75-1 | 4D98E | 01.1998-12.1999 |
| KOMATSU | PC 75R-2 | 4D98E | 01.1999-12.2007 |
| KOMATSU | WA 75-3 | 4D98E | 01.1998-12.2004 |
| KOMATSU | WA 85-3 | 4D98E | 01.1998-12.2004 |
| KOMATSU | WB 70A-1 | 4D98E | 01.2003-12.2006 |
| SAMSUNG | SE 50-3 | 4TNE94 | 01.1992-12.1998 |
