Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MAGNETON
Price:
NZ$ 341.90 including GST
NZ$ 297.30 excluding GST
or four payments of $85.48
with
Learn More
UOM:
each
Product Code:
A9633S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 45 A |
| Bottom Mounting Foot Width (B) | 49.00 mm |
| Diameter (D.1) | 8.00 mm |
| Diameter (D.2) | 8.00 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 162.00 mm |
| Plug Code | PL_9104 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 11.00 mm |
| Pulley Outside Diameter (O.D.1) | 79.00 mm |
| Pulley Outside Diameter (O.D.2) | 57.50 mm |
| Pulley to Mount Distance (A) | 80.00 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| URSUS | C-328 1.9 | S-312B | 01.1963-12.1967 |
| URSUS | C-330 1.9 | S-312-C | 01.1967-12.1987 |
| URSUS | C-330M 1.9 | S-312-C | 01.1986-12.1993 |
Reference Information
| 143701006 | JUBANA |
| 50027970 | MAGNETO |
| 50183000 | MISCELLANEOUS |
| 6569515382 | URSUS |
| 9515382 | MAGNETON |
| A124-330 | MISCELLANEOUS |
| EX-230000 | EXPOM |
| G108030 | BTS TURBO |
| UD104578A | AS-PL |
