Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 492.35 including GST
NZ$ 428.13 excluding GST
or four payments of $123.09
with
Learn More
Product Code:
A1151S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 85 A |
| Bottom Mounting Foot Width (B) | 14.00 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | 8.50 mm |
| Length (L.1) | 15.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 82.50 mm |
| Plug Code | PL_9109 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 13.00 mm |
| Pulley Outside Diameter (O.D.1) | 73.00 mm |
| Pulley Outside Diameter (O.D.2) | 42.00 mm |
| Pulley to Mount Distance (A) | 38.00 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | 216B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 216B3 2.2 | C2.2 | 01.2010-12.2018 |
| CATERPILLAR | 226B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 226B3 2.2 | C2.2 | 01.2010-12.2015 |
| CATERPILLAR | 226D 2.2 | C2.2 | 01.2015-12.2019 |
| CATERPILLAR | 226D3 2.2 | C2.2 | 01.2018-12.2020 |
| CATERPILLAR | 232B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 232D3 2.2 | C2.2 | 01.2018-12.2019 |
| CATERPILLAR | 242B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 247B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | 247B3 2.2 | C2.2T | 01.2010-12.2015 |
| CATERPILLAR | 249D3 2.2 | C2.2 | 01.2018-12.2019 |
| CATERPILLAR | 257B2 2.2 | C2.2 | 01.2007-12.2010 |
| CATERPILLAR | CB22B 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB24B 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB24B XT 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB32B 1.5 | C1.5 | 01.2014-12.2020 |
| CATERPILLAR | CB34B 2.2 | C2.2 | 01.2014-12.2020 |
| CATERPILLAR | CB34B XW 2.2 | C2.2 | 01.2014-12.2016 |
| CATERPILLAR | CB36B 2.2 | C2.2 | 01.2015-12.2020 |
| CATERPILLAR | CC24B 1.5 | C1.5 | 01.2013-12.2020 |
| CATERPILLAR | CC2.6 1.5 | C1.5 | 01.2017-12.2021 |
Reference Information
| 101-08101 | DIXIE |
| 13696N | WAI |
| 316-6963 | CATERPILLAR |
| 394-3496 | CATERPILLAR |
| 399-2625 | CATERPILLAR |
| 399-2803 | CATERPILLAR |
| 437-2770 | CATERPILLAR |
| 445-0262 | CATERPILLAR |
| 477-0766 | CATERPILLAR |
| 487-8175 | CATERPILLAR |
| 487-8176 | CATERPILLAR |
| 490-0056 | CATERPILLAR |
| 529-5978 | CATERPILLAR |
| 705.503.085.030 | WAI |
| 8600566 | DELCO |
| 8600567 | DELCO |
| 90-01-4758 | WILSON |
| A-1807 | DIXIE |
| ALD9567 | KRAUF |
| G102561 | BTS TURBO |
| UD30396A | AS-PL |
