Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 482.32 including GST
NZ$ 419.41 excluding GST
or four payments of $120.58
with
Learn More
Product Code:
A01383S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 33.50 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11.00 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 165.00 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57.00 mm |
| Plug Code | PL_9104 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 9.00 mm |
| Pulley Outside Diameter (O.D.1) | 67.00 mm |
| Pulley Outside Diameter (O.D.2) | 43.00 mm |
| Pulley to Mount Distance (A) | 56.00 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | YARIS (_P9_) 1.3 VVT-i (SCP90_, SCP90R) | 2SZ-FE | 08.2005-11.2010 |
Reference Information
| 0124225033 | BOSCH |
| 0124225078 | BOSCH |
| 034382 | DA SILVA |
| 1986A01973 | BOSCH |
| 93330319 | GMC |
| 93333319 | GMC |
| BREF0321986A01973 | CARWOOD GROUP |
| SG7S018 | VALEO |
| UD103325A | AS-PL |
