Brand new AS-PL Alternator
PREMIUM LINE
SEG Automotive
BOSCH
Price:
NZ$ 437.71 including GST
NZ$ 380.62 excluding GST
or four payments of $109.43
with
Learn More
Product Code:
S01145(SEG)
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 217.00 mm |
| Mount Hole Center - Center (O.1) | 91.00 mm |
| Mount Hole Center - Center (O.2) | 124.00 mm |
| Mount Hole Center - Center (O.3) | 74.00 mm |
| Mount Hole Diameter (C.1) | 9.00 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | 9.00 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 14.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 64.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 110 | 9HL(DV6C) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 110 | 9HR(DV6C) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 90 | 9HJ(DV6DTEDM) | 07.2010- |
| CITROËN | BERLINGO Box Body/MPV (B9) 1.6 HDi 90 | 9HP(DV6DTED) | 07.2010- |
| CITROËN | BERLINGO MULTISPACE (B9) 1.6 HDi 90 | 9HJ(DV6DTEDM) | 07.2010- |
| CITROËN | BERLINGO MULTISPACE (B9) 1.6 HDi 90 | 9HP(DV6DTED) | 07.2010- |
| CITROËN | C3 I (FC_, FN_) 1.4 16V HDi | 8HY(DV4TED4) | 02.2002-06.2008 |
| CITROËN | C3 I (FC_, FN_) 1.4 HDi | 8HX(DV4TD) | 02.2002-12.2009 |
| CITROËN | C3 I (FC_, FN_) 1.4 HDi | 8HZ(DV4TD) | 02.2002-12.2009 |
| CITROËN | C3 PICASSO (SH_) 1.6 HDi 110 | 9HR(DV6C) | 05.2010-02.2013 |
| CITROËN | C4 GRAND PICASSO I (UA_) 1.6 HDi 110 | 9HR(DV6C) | 09.2010-08.2013 |
| CITROËN | C4 II (NC_) 1.6 HDi 110 | 9HR(DV6C) | 11.2009- |
| CITROËN | C4 II (NC_) 1.6 HDi 90 | 9HJ(DV6DTEDM) | 11.2009- |
| CITROËN | C4 II (NC_) 1.6 HDi 90 | 9HP(DV6DTED) | 11.2009- |
| CITROËN | C4 PICASSO I MPV (UD_) 1.6 HDi 110 | 9HR(DV6C) | 09.2010-08.2013 |
| CITROËN | DS3 Convertible 1.6 BlueHDi 100 | BHY(DV6FD) | 07.2014-07.2015 |
| CITROËN | DS3 (SA_) 1.4 HDi 70 (SA8HP4) | 8HP(DV4C) | 04.2010-07.2015 |
| CITROËN | DS3 (SA_) 1.4 HDi 70 (SA8HP4) | 8HR(DV4C) | 04.2010-07.2015 |
| CITROËN | DS3 (SA_) 1.6 BlueHDi 100 | BHY(DV6FD) | 07.2014-07.2015 |
| CITROËN | DS4 (NX_) 1.6 HDi 110 | 9HR(DV6C) | 04.2011-07.2015 |
| CITROËN | DS4 (NX_) 1.6 THP 200 | 5FU(EP6CDTX) | 04.2011-07.2015 |
| CITROËN | DS4 (NX_) 1.6 THP 200 | 5FU(EP6DTX) | 04.2011-07.2015 |
| CITROËN | DS5 1.6 HDi 110 | 9HR(DV6C) | 11.2011-07.2015 |
| FIAT | SCUDO Van (270_, 272_) 2.0 D Multijet | RH02 | 05.2011-03.2016 |
| OPEL | VIVARO C Van (K0) 1.5 4x4 | D15DTH(DV5RUC) | 03.2019- |
| PEUGEOT | 206 Hatchback (2A/C) 1.4 HDi eco 70 | 8HX(DV4TD) | 09.2001-04.2009 |
| PEUGEOT | 206 Hatchback (2A/C) 1.4 HDi eco 70 | 8HZ(DV4TD) | 09.2001-04.2009 |
| PEUGEOT | 206 SW (2E/K) 1.4 HDi | 8HX(DV4TD) | 07.2002-02.2007 |
| PEUGEOT | 206 Van 1.4 HDi | 8HX(DV4TD) | 09.2001-03.2009 |
| PEUGEOT | 206 Van 1.4 HDi | 8HZ(DV4TD) | 09.2001-03.2009 |
| PEUGEOT | 208 I (CA_, CC_) 1.4 HDi | 8HP(DV4C) | 03.2012-12.2019 |
| PEUGEOT | 208 I (CA_, CC_) 1.4 HDi | 8HR(DV4C) | 03.2012-12.2019 |
| PEUGEOT | 208 I (CA_, CC_) 1.6 HDi | 9HD(DV6C) | 03.2012-12.2019 |
| PEUGEOT | 208 I (CA_, CC_) 1.6 HDi | 9HJ(DV6DTEDM) | 03.2012-12.2019 |
| PEUGEOT | 208 I (CA_, CC_) 1.6 HDi | 9HP(DV6DTED) | 03.2012-12.2019 |
| PEUGEOT | 307 (3A/C) 1.4 HDi | 8HX(DV4TD) | 10.2001-06.2005 |
| PEUGEOT | 307 (3A/C) 1.4 HDi | 8HZ(DV4TD) | 10.2001-06.2005 |
| PEUGEOT | 308 SW I (4E_, 4H_) 1.6 HDi | 9HP(DV6DTED) | 11.2009-10.2014 |
| PEUGEOT | 5008 (0U_, 0E_) 1.6 HDi | 9HR(DV6C) | 08.2010-03.2017 |
| PEUGEOT | 508 I (8D_) 1.6 HDi | 9HD(DV6CTED) | 02.2012-12.2018 |
| PEUGEOT | 508 I (8D_) 1.6 HDi | 9HL(DV6C) | 11.2010-12.2018 |
| PEUGEOT | 508 I (8D_) 1.6 HDi | 9HR(DV6C) | 11.2010-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HL(DV6C) | 02.2012-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HL(DV6C) | 11.2010-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HR(DV6C) | 02.2012-12.2018 |
| PEUGEOT | 508 SW I (8E_) 1.6 HDi | 9HR(DV6C) | 11.2010-12.2018 |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi 90 | 9HJ(DV6DTEDM) | 04.2010- |
| PEUGEOT | PARTNER Box Body/MPV 1.6 HDi 90 | 9HP(DV6DTED) | 04.2010- |
| PEUGEOT | PARTNER Platform/Chassis 1.6 HDi | 9HT(DV6BTED4) | 01.2009- |
| PEUGEOT | PARTNER Platform/Chassis 1.6 HDi 16V | 9HS(DV6TED4BU) | 01.2009- |
| PEUGEOT | PARTNER Platform/Chassis 1.6 HDi 16V | 9HX(DV6AUTED4) | 01.2009- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi 90 | 9HJ(DV6DTEDM) | 04.2010- |
| PEUGEOT | PARTNER TEPEE 1.6 HDi 90 | 9HP(DV6DTED) | 04.2010- |
