Price:
NZ$ 570.10 including GST
NZ$ 495.74 excluding GST
or four payments of $142.53
with
Learn More
UOM:
each
Product Code:
S6636S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 3 kW |
| Length (L.1) | 317 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 49 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 5130 | ||
| CASE | 5140 | ||
| CASE | 5150 | ||
| CASE | 5160 | ||
| CASE | 6130 | ||
| CASE | 6140 | ||
| CASE | 6150 | ||
| CASE | 6160 | ||
| CASE | 7130 | ||
| CASE | 7140 | ||
| CASE | 7150 | ||
| CASE | 7160 | ||
| CASE | 9230 | ||
| CASE | Patriot 3250 | ||
| CASE | Patriot 4350 | ||
| CASE | Patriot 4430 | ||
| CASE | Patriot 4440 | ||
| CASE | Patriot 4450 | ||
| CASE | Titan 3030 | ||
| CASE | Titan 3040 | ||
| CASE | Titan 3530 | ||
| CASE | Titan 3540 | ||
| CASE | Titan 4030 | ||
| CASE | Titan 4040 | ||
| CASE | Titan 4530 | ||
| CASE | Titan 4540 | ||
| CASE | Trident 5550 | ||
| CASE IH | 5130 | 01.1988-01.1994 | |
| CASE IH | 5140 | 01.1988-01.1994 | |
| CASE IH | 5150 | 01.1988-01.1994 | |
| CASE IH | 5160 | - | |
| CASE IH | 6130 | - | |
| CASE IH | 6140 | - | |
| CASE IH | 6150 | - | |
| CASE IH | 6160 | - | |
| CASE IH | 7130 | - | |
| CASE IH | 7140 | - | |
| CASE IH | 7150 | - | |
| CASE IH | 7160 | - | |
| CASE IH | 9230 | 01.1990-01.1996 | |
| CASE IH | Patriot 3250 | - | |
| CASE IH | Patriot 4350 | - | |
| CASE IH | Patriot 4430 | - | |
| CASE IH | Patriot 4440 | - | |
| CASE IH | Patriot 4450 | - | |
| CASE IH | Titan 3030 | - | |
| CASE IH | Titan 3040 | - | |
| CASE IH | Titan 3530 | - | |
| CASE IH | Titan 3540 | - | |
| CASE IH | Titan 4030 | - | |
| CASE IH | Titan 4040 | - | |
| CASE IH | Titan 4530 | - | |
| CASE IH | Titan 4540 | - | |
| CASE IH | Trident 5550 | - | |
| JOHN DEERE | Engine | [6068T] | |
| JOHN DEERE | Engine | 6068T | - |
| NEW HOLLAND | CR1090 | ||
| NEW HOLLAND | CR1090 | - | |
| NEW HOLLAND | CR780 | ||
| NEW HOLLAND | CR780 | - | |
| NEW HOLLAND | CR790 | ||
| NEW HOLLAND | CR790 | - | |
| NEW HOLLAND | CR890 | ||
| NEW HOLLAND | CR890 | - | |
| NEW HOLLAND | CR990 | ||
| NEW HOLLAND | CR990 | - | |
| NEW HOLLAND | CX880 | ||
| NEW HOLLAND | CX880 | - | |
| NEW HOLLAND | CX890 | ||
| NEW HOLLAND | CX890 | - | |
| NEW HOLLAND | SP370 | ||
| NEW HOLLAND | SP370 | - | |
| NEW HOLLAND | SP370F Guardian | ||
| NEW HOLLAND | SP370F Guardian | - | |
| NEW HOLLAND | SP380F Guardian | ||
| NEW HOLLAND | SP380F Guardian | - | |
| NEW HOLLAND | SP410 | ||
| NEW HOLLAND | SP410 | - | |
| NEW HOLLAND | SP410F Guardian | ||
| NEW HOLLAND | SP410F Guardian | - |
Reference Information
| 190-30249 | ROBERT'S |
| 428000-8560 | DENSO |
| 504384833 | CASE |
| 84150030 | NEW HOLLAND |
| AM-1064 | AUTO MAGNETO |
| STR6998 | ELECTROLOG |
| UD102975S | AS-PL |
