Price:
NZ$ 522.69 including GST
NZ$ 454.51 excluding GST
or four payments of $130.67
with
Learn More
each
S1293S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2.50 kW |
| Length (L.1) | 348 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 1845 | [188D] | 01.1975-12.1982 |
| CASE | 1845S | [188D] | 01.1975-12.1982 |
| CASE | 188 | [188] | 01.1975-12.1978 |
| CASE | 188D | [188] | 01.1975-12.1978 |
| CASE | 310G | [D-188] | 01.1964-12.1970 |
| CASE | 3300 | [D-188] | 01.1979-12.1980 |
| CASE | 3330 | [D-188] | 01.1979-12.1980 |
| CASE | 350 | [188D] | 01.1973-12.1982 |
| CASE | 350B | [188D] | 01.1973-12.1982 |
| CASE | 450 | [207] | 01.1973-12.1978 |
| CASE | 480B 3.1 | [G188D] | 01.1974-12.1978 |
| CASE | 530 | [4-188] | 01.1965-12.1970 |
| CASE | 530 | 01.1966-12.1969 | |
| CASE | 580 3.1 | [188] | 01.1966-12.1971 |
| CASE | 580B 3.1 | [188] | 01.1971-12.1978 |
| CASE | 584C 3.4 | [207] | 01.1979-12.1988 |
| CASE | 584D 3.1 | [188] | 01.1984-12.1988 |
| CASE | 585D | [188] | 01.1975-12.1988 |
| CASE | 586D | [188] | 01.1975-12.1988 |
| CASE | 70+4 | [207] | 01.1970-12.1979 |
| CASE | 85MR2 | [D-188] | 01.1970-12.1979 |
| CASE | 85MR2 | [G-188] | 01.1970-12.1979 |
| CASE | DH5 | [188] | 01.1977-12.1986 |
| CASE | DH5 | [207] | 01.1977-12.1986 |
| CASE | DH5B | [207] | 01.1977-12.1986 |
| CASE | TF1000 | [207] | 01.1970-12.1980 |
| DROTT | 85RM2 | [188] | 01.1971-12.1978 |
Reference Information
| 104198A1 | CASE |
| 104198A2 | CASE |
| 104198A2R | CASE |
| 104202A1 | CASE |
| 10461609 | DELCO |
| 1109143 | DELCO |
| 140-27107 | ROBERT'S |
| 1998505 | DELCO |
| 201-27131 | DIXIE |
| 2743536 | CLARK |
| 410-12034 | J&N |
| 410-12034R | J&N |
| 4307 | LESTER |
| 4307N | WAI / TRANSPO |
| A39839 | CASE |
| A47460 | CASE |
| D2-0125N | JUST PARTS |
| SDR0244 | ARROWHEAD |
| TS-1294 | DIXIE |
| UD102895S | AS-PL |
