Price:
NZ$ 636.19 including GST
NZ$ 553.21 excluding GST
or four payments of $159.05
with
Learn More
UOM:
each
Product Code:
S0963(SEG)
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2.50 kW |
| Length (L.1) | 246 mm |
| Mount Hole Center - Center (O.1) | 95 mm |
| Mount Hole Center - Center (O.2) | 122 mm |
| Mount Hole Center - Center (O.3) | 70 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 27 mm |
| Rotation | CW |
| Spigot Diameter (A) | 83.50 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| IVECO | Daily 35C17 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35C17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 35C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 35C17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 35C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 35C17 P 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35C17 V 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35C17 V/P 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35C18 3.0 | [F1CFL411B] | 06.2022- |
| IVECO | Daily 35C18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 35S15 3.0 | [F1CE0489EIII] | 03.2014- |
| IVECO | Daily 35S15 3.0 | [F1CE3481J] | 03.2014- |
| IVECO | Daily 35S17 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 35S17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 35S17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 35S17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 35S17D 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S17 P 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S17 V 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S17 V/P 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S17 W 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S17 WD 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 35S18 3.0 | [F1CFL4117] | 04.2016- |
| IVECO | Daily 35S18 3.0 | [F1CFL411B] | 06.2022- |
| IVECO | Daily 35S18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 35S18 3.0 | [F1CFL411W] | 04.2016- |
| IVECO | Daily 40C17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 40C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 40C17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 40C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 40C18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 42S18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 45C17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 45C17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 45S17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 45S17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 50C17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 50C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 50C17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 50C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 50C18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 55C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 55C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 55C18 3.0 | [F1CFL4117] | 04.2016- |
| IVECO | Daily 55C18 3.0 | [F1CFL411B] | 06.2022- |
| IVECO | Daily 55C18 3.0 | [F1CFL411W] | 04.2016- |
| IVECO | Daily 55S15 3.0 | [F1CE0489EIII] | 03.2014- |
| IVECO | Daily 55S15 3.0 | [F1CE3481J] | 03.2014- |
| IVECO | Daily 55S17 3.0 4x4 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 55S17 W 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 55S17 W 3.0 4x4 | [F1CE3481C] | 09.2011-02.2014 |
| IVECO | Daily 55S17 WD 3.0 | [F1CE3481C] | 07.2007-08.2011 |
| IVECO | Daily 55S18 3.0 | [F1CFL4117] | 04.2016- |
| IVECO | Daily 55S18 3.0 | [F1CFL411B] | 06.2022- |
| IVECO | Daily 55S18 3.0 | [F1CFL411W] | 04.2016- |
| IVECO | Daily 60C17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 60C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 60C17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 60C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 60C18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 65C17 3.0 | [F1CFL411F] | 03.2014- |
| IVECO | Daily 65C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 65C17 3.0 | [F1CFL411H] | 03.2014- |
| IVECO | Daily 65C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 65C18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 70C15 3.0 | [F1CE0489EIII] | 03.2014- |
| IVECO | Daily 70C15 3.0 | [F1CE3481J] | 03.2014- |
| IVECO | Daily 70C17 3.0 | [F1CFL411F] | 03.2014-04.2016 |
| IVECO | Daily 70C17 3.0 | [F1CFL411H] | 03.2014-04.2016 |
| IVECO | Daily 70C18 3.0 | [F1CFL411B] | 06.2022- |
| IVECO | Daily 70C18 3.0 | [F1CFL411B] | 07.2021- |
| IVECO | Daily 70C18 3.0 4x4 | [F1CFL4117] | 04.2016- |
| IVECO | Daily 70C18 3.0 4x4 | [F1CFL411W] | 04.2016- |
| IVECO | Daily 70S15 3.0 | [F1CE0489EIII] | 03.2014- |
| IVECO | Daily 70S15 3.0 | [F1CE3481J] | 03.2014- |
| IVECO | Daily 70S18 3.0 | [F1CFL4117] | 04.2016- |
| IVECO | Daily 70S18 3.0 | [F1CFL411B] | 06.2022- |
| IVECO | Daily 70S18 3.0 | [F1CFL411W] | 04.2016- |
| IVECO | DAILY IV Platform/Chassis 35C17, 35C17 /P, 35S17, 35S17 /P, 35S17 D | F1CE3481C | 07.2007-08.2011 |
| IVECO | DAILY IV Platform/Chassis 35S17 W, 35S17 WD | F1CE3481C | 07.2007-08.2011 |
| IVECO | DAILY IV Platform/Chassis 55S17 W, 55S17 WD | F1CE3481C | 07.2007-08.2011 |
| IVECO | DAILY IV Van 35C17 V, 35C17 V/P, 35S17 V, 35S17 V/P | F1CE3481C | 07.2007-08.2011 |
| IVECO | DAILY VI Platform/Chassis 35S15, 55S15, 70S15, 70C15 | F1CE0489EIII | 03.2014- |
| IVECO | DAILY VI Platform/Chassis 35S15, 55S15, 70S15, 70C15 | F1CE3481J | 03.2014- |
| IVECO | DAILY VI Platform/Chassis 35S17, 35C17, 40C17, 45S17,45C17, 50C17, 60C17, 65C17,... | F1CFL411F | 03.2014- |
| IVECO | DAILY VI Platform/Chassis 35S17, 35C17, 40C17, 45S17,45C17, 50C17, 60C17, 65C17,... | F1CFL411H | 03.2014- |
| IVECO | DAILY VI Platform/Chassis 35S17, 55S17 4x4 | F1CFL411F | 03.2014- |
| IVECO | DAILY VI Platform/Chassis 35S18, 35C18, 55C18, 55S18, 70C18, 70S18 | F1CFL411B | 06.2022- |
| IVECO | DAILY VI Platform/Chassis 35S18, 42S18, 35C18, 38S18, 40C18, 50C18, 60C18, 65C18,... | F1CFL411B | 07.2021- |
| IVECO | DAILY VI Platform/Chassis 35S18, 55S18, 55C18, 70S18, 70C18 4x4 | F1CFL4117 | 04.2016- |
| IVECO | DAILY VI Platform/Chassis 35S18, 55S18, 55C18, 70S18, 70C18 4x4 | F1CFL411W | 04.2016- |
| IVECO | DAILY VI Van 35S17, 35C17, 40C17, 50C17, 55C17, 60C17, 65C17, 70C17 | F1CE3481C | 03.2014-04.2016 |
| IVECO | DAILY VI Van 35S17, 35C17, 40C17, 50C17, 55C17, 60C17, 65C17, 70C17 | F1CFL411F | 03.2014-04.2016 |
| IVECO | DAILY VI Van 35S17, 35C17, 40C17, 50C17, 55C17, 60C17, 65C17, 70C17 | F1CFL411H | 03.2014-04.2016 |
| IVECO | DAILY VI Van 35S18, 35C18, 40C18, 42S18, 50C18, 60C18, 65C18, 70C18 | F1CFL411B | 07.2021- |
| IVECO | DAILY VI Van 55S18, 55C18, 70S18, 70C18 | F1CFL411B | 06.2022- |
| IVECO | DAILY V Platform/Chassis 55S17W 4x4 | F1CE3481C | 09.2011-02.2014 |
Reference Information
| 0001109365 | BOSCH |
| 1986S00742 | BOSCH |
| 5801287850 | IVECO |
| 69503857 | IVECO |
| BOS0001109365 | WOODAUTO |
| DRS0633 | DELCO |
| STB9365 | KRAUF |
| UD04235(SEG)S | AS-PL |
