Price:
NZ$ 816.93 including GST
NZ$ 710.37 excluding GST
or four payments of $204.23
with
Learn More
each
S01060(SEG)
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 4.20 kW |
| Length (L.1) | 326 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AGCO | 520C | ||
| AGCO | 540C | ||
| AGCO | 670B | ||
| AGCO | 670B EEA | ||
| AGCO | A76 | 01.2008- | |
| AGCO | MT745D 8.4 | ||
| AGCO | MT755D 8.4 | ||
| AGCO | MT765D 8.4 | ||
| AGCO | MT775E 9.8 | ||
| AGCO | R66 | 01.2008- | |
| AGCO | R76 | 01.2008- | |
| AGCO | S67 | 01.2010- | |
| AGCO | S68 | 01.2014- | |
| AGCO | S77 | 01.2010- | |
| AGCO | S78 | 01.2014- | |
| AGCO | S88 | 01.2014- | |
| VALTRA | T120 | ||
| VALTRA | T130 | ||
| VALTRA | T140 | ||
| VALTRA | T160 | ||
| VALTRA | T170 | ||
| VALTRA | T180 | ||
| VALTRA | T190 |
Reference Information
| 0001260025 | BOSCH |
| 0001260026 | BOSCH |
| 0001260035 | BOSCH |
| 10010049OV | ITAB AUTOMOTIVE |
| 10021117OV | ITAB AUTOMOTIVE |
| 11.131.727 | ISKRA / LETRIKA |
| 11.132.356 | ISKRA / LETRIKA |
| 113570 | CARGO |
| 162000090722 | NEW HOLLAND |
| 19992N | WAI / TRANSPO |
| 20401940OE | REAL |
| 20419711BN | REAL |
| 20419711OE | REAL |
| 25-4033 | ELSTOCK |
| 254856 | KUHNER |
| 254856B | KUHNER |
| 254856M | KUHNER |
| 254856S | KUHNER |
| 47111575 | CASE |
| 5010948G | MEAT & DORIA |
| 569018D1 | AGCO |
| 6010049.1 | SANDO |
| 6021117.0 | SANDO |
| 6021117.1 | SANDO |
| 72735803 | MAHLE |
| 800.008.113.010 | PSH |
| 800.008.113.090 | PSH |
| 800.008.113.211 | PSH |
| 800.008.113.280 | PSH |
| 800.008.113.311 | PSH |
| 8103 | CEVAM |
| 83646500 | VALTRA |
| 836673290 | AGCO |
| 836866817 | AGCO |
| 836873088 | AGCO |
| 836873290 | HESSTON |
| 836873457 | AGCO |
| 84284540 | CASE |
| 87693781 | NEW HOLLAND |
| 87751000 | NEW HOLLAND |
| 88213744 | POWERMAX |
| 89732200 | VALTRA |
| 91-23-6582 | WILSON |
| AZF4190 | ISKRA / LETRIKA |
| AZF4369 | ISKRA / LETRIKA |
| CGB-23257 | AINDE |
| CST10049GS | CASCO |
| CST21117AS | CASCO |
| CST21117GS | CASCO |
| DRS0569 | DELCO |
| DS1679 | DELCO |
| F032113570 | CARGO |
| IS0836 | ISKRA / LETRIKA |
| LRS02361 | LUCAS |
| LRS2361 | LUCAS |
| MAHMS175 | WOODAUTO |
| MAV120490 | SIOM |
| MAV231170 | SIOM |
| MS175 | MAHLE |
| MS591 | MAHLE |
| PRSL814 | 3EFFE |
| S100701 | BTS TURBO |
| S101605 | BTS TURBO |
| S103289 | BTS TURBO |
| S104110 | BTS TURBO |
| S12BH0917 | SIDAT |
| S135.358 | PSH |
| S145.465 | PSH |
| S5001L | PRESTOLITE |
| STI3570 | KRAUF |
| STR10018 | ELECTROLOG |
| STR50592 | WOODAUTO |
| STR60609 | WOODAUTO |
| STR7894 | ELECTROLOG |
| STRL814 | 3EFFE |
| STRL814L | 3EFFE |
| UD04462(SEG)S | AS-PL |
| V836866817 | AGCO |
| V836873457 | AGCO |
| VPF7263 | VALTRA |
| WOOSTR50592 | WOODAUTO |
| WOOSTR60609 | WOODAUTO |
