Price:
NZ$ 386.35 including GST
NZ$ 335.96 excluding GST
or four payments of $96.59
with
Learn More
UOM:
each
Product Code:
A2158S
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 215 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81 mm |
| Plug Code | PL_4505 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 12 mm |
| Pulley Outside Diameter (O.D.1) | 82 mm |
| Pulley Outside Diameter (O.D.2) | 50 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | Solid |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Gemini 1.5 TD | [4EC1T] | 02.1988-12.1989 |
| ISUZU | Gemini 1.5 TD | [4EC1T] | 02.1988-12.1990 |
| ISUZU | GEMINI (JT) 1.5 TD | 4EC1T | 02.1988-12.1990 |
| ISUZU | GEMINI Saloon (JT) 1.5 TD | 4EC1T | 02.1988-12.1989 |
| ISUZU | MIDI Bus (94000, 98000) 2.0 TD (98000) | 4FC1T | 01.1989-08.1992 |
| ISUZU | MIDI Bus (94000, 98000) 2.2 D 4WD (94000) | 4FD1 | 06.1988-08.1992 |
| ISUZU | MIDI Bus (94000, 98000) 2.2 D (98000) | 4FD1 | 06.1988-08.1992 |
| ISUZU | MIDI Van (94000, 98000) 2.0 TD (98000) | 4FC1T | 01.1989-08.1992 |
| ISUZU | MIDI Van (94000, 98000) 2.2 D 4WD (94000) | 4FD1 | 06.1988-08.1992 |
| ISUZU | MIDI Van (94000, 98000) 2.2 D (98000) | 4FD1 | 06.1988-08.1992 |
| ISUZU | MIDI Van (98000N) 2.2 D | 4FD1 | 06.1988-08.1992 |
| ISUZU | MIDI Van (98000N) 2.2 D 4WD | 4FD1 | 06.1988-08.1992 |
| OPEL | Corsa A 1.5 TD | [15DT(T4EC1)] | 03.1988-03.1993 |
| OPEL | CORSA A Hatchback (S83) 1.5 D (F08, M08, F68, M68) | 15D(4EC1) | 09.1987-03.1993 |
| OPEL | CORSA A Hatchback (S83) 1.5 TD (F08, M08, F68, M68) | 15DT(T4EC1) | 03.1988-03.1993 |
| OPEL | CORSA A Hatchback Van (S83) 1.5 D (F08, W5L) | 15D(4EC1) | 06.1987-04.1989 |
| OPEL | Corsa A TR 1.5 TD | [15DT(T4EC1)] | 10.1987-03.1993 |
| OPEL | CORSA A TR (S83) 1.5 D (F11, M11, F19, M19) | 15D(4EC1) | 10.1987-11.1992 |
| OPEL | CORSA A TR (S83) 1.5 TD (F11, M11, F19, M19) | 15DT(T4EC1) | 10.1987-03.1993 |
Reference Information
| 0986037841 | BOSCH |
| 10441719 | ALANKO |
| 11.209.018 | ISKRA / LETRIKA |
| 11.209.404 | ISKRA / LETRIKA |
| 11.209.502 | ISKRA / LETRIKA |
| 1204119 | GENERAL MOTORS |
| 1204133 | GENERAL MOTORS |
| 1204138 | OPEL |
| 1204166 | OPEL |
| 12060305 | EUROTEC |
| 135.801.070.080 | WAI |
| 135.801.070.340 | WAI |
| 135.801.070.461 | WAI |
| 135.801.070.785 | WAI |
| 20020119AV | ITAB AUTOMOTIVE |
| 20100939 | PRESTOLITE |
| 20145911BN | REAL |
| 2020119.0 | SANDO |
| 22424N | WAI |
| 228118702 | DRI |
| 28-1908 | ELSTOCK |
| 3111340 | HENKEL PARTS |
| 3111341 | HENKEL PARTS |
| 40871RI | KUHNER |
| 40871RIM | KUHNER |
| 40871RIR | KUHNER |
| 437135 | VALEO |
| 445920 | LOGISTIK |
| 56374 | EAI |
| 89212246 | POWERMAX |
| 8970301440 | ISUZU |
| 8970430640 | ISUZU |
| 8970730460 | ISUZU |
| 8EL012429-031 | HELLA |
| 8EL731758-001 | HELLA |
| 9212246 | POWERMAX |
| 9306 | CEVAM |
| 97030144 | ISUZU |
| 97042325 | OPEL |
| A130.156 | WAI |
| AAK3151 | ISKRA / LETRIKA |
| AAK3163 | ISKRA / LETRIKA |
| AAK3175 | ISKRA / LETRIKA |
| AHI119A | AUTOTEAM |
| AL01083 | TMI |
| ALH0382 | KRAUF |
| ALT0216 | 3EFFE |
| ALT3129 | ELECTROLOG |
| ALT32093 | WOODAUTO |
| ALT5450A | SIOM |
| ALTV008 | WOODAUTO |
| ALTW993 | 3EFFE |
| ANM35518 | ANDEL |
| CAL20119AS | CASCO |
| DRA3298 | DELCO |
| G104649 | BTS TURBO |
| IA9018 | ISKRA / LETRIKA |
| JA871IR | HELLA |
| L37840 | ATL AUTOTECHNIK |
| LR170-419 | HITACHI |
| LR170-419B | HITACHI |
| LR170-422 | HITACHI |
| LRA01424 | LUCAS |
| LRA1424 | LUCAS |
| MG585 | MAHLE |
| R1030092 | VAUXHALL |
| UD103115A | AS-PL |
| WOOALT32093 | WOODAUTO |
| WOOALTV008 | WOODAUTO |
