Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBA
Price:
NZ$ 147.69 including GST
NZ$ 128.43 excluding GST
or four payments of $36.92
with
Learn More
each
S9656S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Length (L.1) | 178 mm |
| Mount Hole Center - Center (O.1) | 45 mm |
| Mount Hole Diameter (C.1) | 7 mm |
| Mount Hole Diameter (C.2) | 7 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 40 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| POLARIS | Frontier | [784cc] | 01.2003-12.2004 |
| POLARIS | Frontier | [784cc] | 01.2003-12.2005 |
| POLARIS | Ranger 700 4x4 | [683cc] | 01.2005-12.2009 |
| POLARIS | Ranger 700 6x6 | [683cc] | 01.2006-12.2009 |
| POLARIS | Ranger 800 4x4 | [760cc] | 01.2010-12.2011 |
| POLARIS | Ranger 800 4x4 | [760cc] | 01.2011-12.2012 |
| POLARIS | Ranger 800 6x6 | [760cc] | 01.2010-12.2012 |
| POLARIS | Ranger 800 XP 4x4 | [760cc] | 01.2012-12.2012 |
| POLARIS | Ranger RZR 4 800 EFI | [760cc] | 01.2010-12.2011 |
| POLARIS | Ranger RZR 800 EFI | [760cc] | 01.2008-12.2012 |
| POLARIS | Ranger RZR S 800 EFI | [760cc] | 01.2009-12.2012 |
| POLARIS | Sportsman 600 | [597cc] | 01.2003-12.2004 |
| POLARIS | Sportsman 600 | [597cc] | 01.2004-12.2005 |
| POLARIS | Sportsman 6x6 | [499cc] | 01.2009-12.2009 |
| POLARIS | Sportsman 700 | [683cc] | 01.2004-12.2006 |
| POLARIS | Sportsman 700 4x4 | [683cc] | 01.2004-12.2006 |
| POLARIS | Sportsman 700 EFI | [683cc] | 01.2002-12.2007 |
| POLARIS | Sportsman 700 EFI 4x4 | [683cc] | 01.2004-12.2006 |
| POLARIS | Sportsman 800 EFI | [760cc] | 01.2005-12.2009 |
| POLARIS | Sportsman 800 EFI | [760cc] | 01.2008-12.2009 |
| POLARIS | Sportsman 800 HO | [760cc] | 01.2008-12.2009 |
| POLARIS | Sportsman Big Boss 800 EFI 6x6 | [760cc] | 01.2009-12.2010 |
| POLARIS | Sportsman MV7 | [683cc] | 01.2005-12.2005 |
| POLARIS | Sportsman X2 700 EFI | [683cc] | 01.2008-12.2008 |
| POLARIS | Sportsman X2 800 EFI | [760cc] | 01.2007-12.2009 |
Reference Information
| 106-10422 | ROBERT'S |
| 18648 | LESTER |
| 18648N | WAI / TRANSPO |
| 242-06158 | DIXIE |
| 400.529.092.190 | PSH |
| 4010417 | POLARIS |
| 4011584 | POLARIS |
| 4012032 | POLARIS |
| 410-54040 | J&N |
| 71-26-18648 | WILSON |
| PO2-0006N | JUST PARTS |
| RS41237 | DELCO |
| S132.908 | PSH |
| SMU0271 | ARROWHEAD |
| STR75443 | WOODAUTO |
| STU8648 | KRAUF |
| UD19120S | AS-PL |
| WOOSTR75443 | WOODAUTO |
Video/Publications
