Remanufactured AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 369.09 including GST
NZ$ 320.95 excluding GST
or four payments of $92.27
with
Learn More
each
S0064SR
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 270 mm |
| Mount Hole Center - Center (O.1) | 81.5 mm |
| Mount Hole Center - Center (O.2) | 115.5 mm |
| Mount Hole Center - Center (O.3) | 81.5 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 24 mm |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Rotation | CW |
| Spigot Diameter (A) | 81.3 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | Jumper 2.8 Diesel | [8140.63] | 01.1999- |
| CITROEN | Jumper 2.8 HDi | [8140.43N] | 05.2004- |
| CITROEN | Jumper 2.8 TD | [8140.43] | 10.1999- |
| FIAT | Ducato 2.5 Diesel | [8140.67] | 03.1994-04.2002 |
| FIAT | Ducato 2.5 Diesel 4x4 | [8140.67] | 03.1994-04.2002 |
| FIAT | Ducato 2.5 TDi | [8140.47] | 03.1994-03.2000 |
| FIAT | Ducato 2.5 TDi | [8140.47] | 03.1994-04.2002 |
| FIAT | Ducato 2.5 TDi 4x4 | [8140.47] | 03.1994-04.2002 |
Reference Information
LES0502 5802Y1 5802Y2 63522230130 458504 3118664 500.513.093.010 AZE4142 PRSL015 CST10152AS MS1085 5802-Y2 5802-Y1 DRS7020 CMA-621340 11.139.443 S12BH0097A2 EAA-121340 72735639 330956 RNL1702 LRT00132 K1300198080 TP9014 71721242 33221N 8EA737146-001 11752 42017020 5010016 TT15593 1516827R RE8289N A17020 S510231 0986017020 9.4321E+11 STR50078 0001218159 130019808 MS11 AC-CBS0973 H5010016 10441230 STX200091 331350 5802-EC 318052092 QRS1711 103554 22.0973 8017020 STX200091R 220165A 71782324 3163 10010152AV MSRC973 131955508 STR79677 10973 12.71005 46231643 MAV6810 11017020 ST00694 46231646 AES1232 CS973 SG0069 STRL015 STA0119R 113451 9.43251E+11 35259950 011-001-000335R STX200115 FT74203 AZMT-53-010-1432 STR1319 500.513.093.310 8212122 20401251BN 25-2011 1300198080 IS9436 6010152 WG2012795 5802V4 5802EC STX200115R 0001218759 8EA012528-161 SBO152A 220165 SS289 S-50078Video/Publications
