Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 493.74 including GST
NZ$ 429.34 excluding GST
or four payments of $123.44
with
Learn More
each
A0933S
1
Information
0124525186Specifications
| Amp | 150 A |
| Diameter (D.1) | M12x1.75 mm |
| Diameter (D.2) | 13 mm |
| Diameter (D.3) | 13 mm |
| Length (L.1) | 210 mm |
| Mount Inside Length or Pad Mount C-C (C) | 101 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 13 mm |
| Pulley Type | No Pulley |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 580N | 01.2015- | |
| CASE | 580N EP | 01.2015- | |
| CASE | 580SN | 01.2015-12.2016 | |
| CASE | 580SN WT | 01.2015-12.2016 | |
| CASE | 590SN | 01.2015-12.2016 | |
| CASE | Magnum 215 | 01.2006-12.2010 | |
| CASE | Magnum 245 | 01.2006-12.2010 | |
| CASE | Magnum 275 | 01.2006-12.2010 | |
| CASE | Magnum 305 | 01.2006-12.2010 | |
| CASE | Magnum 335 | 01.2007-12.2010 | |
| CASE | MX215 | 01.2006- | |
| CASE | MX245 | 01.2006- | |
| CASE | MX275 | 01.2006- | |
| CASE | MX305 | 01.2006- | |
| CASE | SR240 | 01.2015- | |
| CASE | SR270 | 01.2015- | |
| CASE | SV280 | 01.2015- | |
| CASE | SV300 | 01.2015-12.2016 | |
| CASE | SV340 | 01.2016- | |
| CASE | Titan 3020 | 01.2006-12.2012 | |
| CASE | Titan 3520 | 01.2006-12.2012 | |
| CASE | Titan 4020 | 01.2006-12.2012 | |
| CASE | Titan 4520 | 01.2006-12.2012 | |
| CASE | TR310 | 01.2015- | |
| CASE | TR340 | 01.2015- | |
| CASE | TV380 | 01.2015- | |
| CASE | WD1203 | 01.2013-12.2015 | |
| CASE | WD1204 | 01.2014-12.2015 | |
| CASE | WD1504 | 01.2014-12.2015 | |
| CASE | WD1903 | 01.2013-12.2015 | |
| CASE | WD1904 | 01.2014-12.2015 | |
| CASE | WD2104 | 01.2014-12.2015 | |
| CASE | WD2303 | 01.2014-12.2015 | |
| CASE | WD2304 | 01.2014-12.2015 | |
| CASE | WD2504 | 01.2014-12.2015 | |
| NEW HOLLAND | B110C | 01.2015-12.2016 | |
| NEW HOLLAND | B110C Livery | 01.2016-12.2019 | |
| NEW HOLLAND | B95C | 01.2015-12.2016 | |
| NEW HOLLAND | B95C Livery | 01.2016-12.2019 | |
| NEW HOLLAND | B95CLR | 01.2015-12.2016 | |
| NEW HOLLAND | B95CTC | 01.2015-12.2016 | |
| NEW HOLLAND | B95CTC | 01.2016-12.2019 | |
| NEW HOLLAND | C232 | 01.2015- | |
| NEW HOLLAND | C238 | 01.2015- | |
| NEW HOLLAND | L228 | 01.2015- | |
| NEW HOLLAND | L230 | 01.2015-12.2016 | |
| NEW HOLLAND | L234 | 01.2016- | |
| NEW HOLLAND | Speedrower 130 | 01.2014-12.2015 | |
| NEW HOLLAND | Speedrower 130 | ||
| NEW HOLLAND | Speedrower 160 | 01.2014-12.2015 | |
| NEW HOLLAND | Speedrower 200 | 01.2014-12.2015 | |
| NEW HOLLAND | Speedrower 200 | ||
| NEW HOLLAND | Speedrower 220 | 01.2014-12.2015 | |
| NEW HOLLAND | Speedrower 240 | 01.2014-12.2015 | |
| NEW HOLLAND | Speedrower 240 | ||
| NEW HOLLAND | Speedrower 260 | 01.2014- | |
| NEW HOLLAND | T8010 | 01.2006-12.2011 | |
| NEW HOLLAND | T8020 | 01.2006-12.2011 | |
| NEW HOLLAND | T8030 | 01.2006-12.2012 | |
| NEW HOLLAND | T8040 | 01.2006-12.2011 | |
| NEW HOLLAND | T8050 | 01.2007-12.2010 | |
| NEW HOLLAND | TG215 | 01.2006-12.2011 | |
| NEW HOLLAND | TG245 | 01.2006-12.2011 | |
| NEW HOLLAND | TG275 | 01.2006-12.2012 | |
| NEW HOLLAND | TG305 | 01.2006-12.2011 |
Reference Information
| 0124525186 | BOSCH |
| 0124525242 | BOSCH |
| 0124525245 | BOSCH |
| 0124525246 | BOSCH |
| 052.000.328.212 | PSH |
| 20010A04AV | ITAB AUTOMOTIVE |
| 20010A04OV | ITAB AUTOMOTIVE |
| 2010140ABN | REAL |
| 2010140AOE | REAL |
| 2010A04.0 | SANDO |
| 2010A04.1 | SANDO |
| 220-30276 | ROBERT'S |
| 220-30276NOE | ROBERT'S |
| 48102484 | JOHN DEERE |
| 554360RI | KUHNER |
| 635.532.150.010 | PSH |
| 87715397 | CASE |
| A134.767 | PSH |
| ABOA04A | AUTOTEAM |
| ALT10244 | ELECTROLOG |
| CAL10A04AS | CASCO |
| CAL10A04GS | CASCO |
| UD90884A | AS-PL |
