Associated Numbers
- DENSO 438000-2140 4380002141
- GENERAL MOTORS 12665560, 12667973
- LESTER 16349
Specifications
Diameter (D.1) | M10x1.5 mm |
Diameter (D.2) | 11 mm |
Length (L.1) | 215 mm |
Mount Hole Center - Center (O.1) | 23 mm |
Mount Hole Center - Center (O.2) | 83 mm |
Mount Hole Center - Center (O.3) | 97.5 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 17 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CADILLAC | CT6 | 2016- | |
CHEVROLET | TRAVERSE | 2016- | |
HOLDEN | ACADIA | 2016- |
Reference Information
Denso: 438000-2140
GM: 12665560, 12667973
