Specifications
B+ Stud Diameter & Thread Pitch (B+) | M12x1.75 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M12x1.75 mm |
Coil Bolt Length | 28 mm |
L.B+ | 45 mm |
Length (L.1) | 119 mm |
Outside Diameter (O.D.1) | 65.4 mm |
Outside Diameter (O.D.2) | 65 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Reference Information
MITM373X16671 054.000.269.132 M373X16671 S214710042S CSO35620GS 20337026OE SSO35620.1 UD16787(MITSUBISHI)SS ELE376200Video/Publications
M9T20871 M009T84771 M9T20872 M9T88371 M009T80471 M009T85371 M009T80472 M009T87373 M009T83671 M009T88371 M9T21171 M9T85371 M9T87373 M9T83671 M9T20171 M9T80471 M9T80472 M9T84771 M009T20171 M9T80473 M009T21171 M009T20872 M009T20871 M009T80473Add Your Number
