Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 13 mm |
| Inside Diameter (I.D.1) | 24.7 mm |
| L.B+ | 13 mm |
| Length (L.1) | 73.5 mm |
| Outside Diameter (O.D.1) | 51 mm |
| Outside Diameter (O.D.2) | 45 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
CSO35124GS SSO35124.1 MITM371XA4473 ELE371240 UD16765(MITSUBISHI)SS M371XA4473 054.001.245.370 20337421OE M371XA4473AM SOL5050Video/Publications
M002T85271 M8T75071A ME201650 M002T84171ZT M002T87971 MD314167 M2T87171ZT M000T35274 MD348221 M000T35276 M000T35273 M2T85371 M000T35272 M002T88071 M008T71371 M008T75371 M002T84071 M002T88271 S5007 M002T84171 M002T84571 M2T87071 1810A053 1810A050 M1T90081A M8T71371 M8T75371 MD312858 MD312857 MD344183 M008T75073A MD344182 M002TS0571 M8T71371ZE S5036 M002T87171 M002TS0575 M002T87371 M0T90482ZC M1T90081 M002T85371 M8T75073A M2T88071 M2T88271 M2T84171ZT M2T84071 M002T87171ZT ME204425 ME204424 M2TS0571 M2T84781 M2TS0575 M001T90081A M2T85271 S5026 M008T75071 S5223 M008T75073 M2T87971 M008T75074 ME202970 S5342S 0001107037 S5050 M001T90081 S5099 M2T87171 M2T87371 M8T71471 M8T75074 M8T75073 MD315547 M8T75071 M2T84571 3610038090 M008T75071A M2T84171 M008T71371ZE M0T35274 M0T35276 M002T87071 M0T35272 S5138 M0T35273Add Your Number
