Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 7 mm |
Inside Diameter (I.D.1) | 25 mm |
L.B+ | 16 mm |
Length (L.1) | 64 mm |
Outside Diameter (O.D.1) | 54 mm |
Outside Diameter (O.D.2) | 46 mm |
Unit Type | VALEO |
Voltage | 12 V |
Reference Information
595838 UD814612(VALEO)SS 054.001.203.500 20379771OE CSO15177GS SSO15177.1 36023177Video/Publications
TS2234 TS2257 TS2229 TS22E28Add Your Number
