Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 12.5 mm |
| Inside Diameter (I.D.1) | 27 mm |
| L.B+ | 23.5 mm |
| Length (L.1) | 67 mm |
| Outside Diameter (O.D.1) | 56.3 mm |
| Outside Diameter (O.D.2) | 50 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Reference Information
054.000.816.010 F000SH0209 ZM3571 UD49126SS 3571 227238 SOL1248 SSB3571Video/Publications
S0708S F000AL0128 F000AL0139 F000AL0136 F000AL0135 F000AL0138 F000AL0137Add Your Number
