Specifications
Height (H.1) | 111.5 mm |
Inside Diameter (I.D.1) | 10.5 mm |
Mount Hole Center - Center (O.1) | 90.5 mm |
Mount Hole Center - Center (O.2) | 38 mm |
Mount Hole Center - Center (O.3) | 81 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
Spigot Diameter (A) | 69 mm |
Unit Type | BOSCH |
Reference Information
UD48686SBR UD48158SBRVideo/Publications
S0479 0001148509 0001115069 S0595 0001148009 S0487Add Your Number
