Specifications
| Kilowatt | 3.5 kW |
| Length (L.1) | 275 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 27 mm |
| Rotation | CW |
| Spigot Diameter (A) | 81.5 mm |
| Unit Type | DONGFENG |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DWEIFANG | Engine | ||
| FAWDE | Engine | ||
| WEICHAI | Engine | [WP2.5D22E2] |
Reference Information
QDJ1409Z-P WOOSTR86016 690.559.112.200 UD30087S STR86016Add Your Number
