Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 228 mm |
Mount Hole Center - Center (O.1) | 66 mm |
Mount Hole Center - Center (O.2) | 111 mm |
Mount Hole Center - Center (O.3) | 69 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 8 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | 300 M 3.5 V6 24V | [EGG] | 07.1998-08.2000 |
CHRYSLER | 300 M 3.5 V6 24V | [EGG] | 08.2000-09.2004 |
DODGE | Intrepid 3.2 | [EGW] | 04.1998-09.2004 |
DODGE | Intrepid 3.2 | [EKK] | 04.1998-09.2004 |
DODGE | Intrepid 3.5 ES | [EGG] | 04.1998-09.2004 |
Reference Information
17951N 830.594.103.030 228000-6113 228000-6112 107098 UD19719S 254842 KRL609346AB STN3411 428000-1550 4609346AB 25-5086 6040280 830.594.103.265 20432082BN 91-29-5473 RL609346AB LRS03923 4609346 9811 634052102 CST40280AS ST02050 04609346AB 04609346ADAdd Your Number
