Specifications
Kilowatt | 2 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
GEHL | MG747B | 01.1984-12.1994 | |
HYSTER | H40 | 01.1985-12.2008 | |
HYSTER | S25 | 01.1985-12.2008 | |
KOMATSU | PC50 | 01.1990- | |
THERMO KING | Engine | [C201] | 01.1984- |
Reference Information
028000-7004 128000-0020 20552 128000-0960 LRS1142 DSN2128 25-1106 581100-0860 20552V LRS01142 UD810320(DENSO)S 65-26201-7059 5811001661 112473 5811001660 600-813-1750 028000-7001 028000-7000 5811001664 028000-7003 5811001663 028000-7002 GSSN2128-N 5811001662 130.598.092.260 8023898 8973168950 128000-3100 128000-3101 8941233870 DENDSN2128 228000-9690 228080-9690 20552DAdd Your Number
