Specifications
Kilowatt | 0.7 kW |
Length (L.1) | 205 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | M12x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 33 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Civic 1.4 | [L13A7] | 09.2005-09.2008 |
HONDA | Jazz 1.2 i-DSi | [L12A1] | 03.2002-07.2008 |
HONDA | Jazz 1.2 i-DSi | [L12A4] | 03.2002-07.2008 |
HONDA | Jazz 1.3 i-DSi | [L13A1] | 03.2002-07.2008 |
HONDA | Jazz 1.4 i-DSi | [L13A5] | 12.2006-10.2008 |
HONDA | Jazz 1.4 i-DSi | [L13A6] | 12.2006-10.2008 |
Reference Information
120.566.092.260 986027020 MAV424130A CST40413AS 31200-RSH-E01 STRE381 AEY2644 20432314OE PRSE381 CST40413GS 8EA011611-941 DSN1398 6040413 DV4DJ STN0125 DRS0879 20432314BN 428000-4140 STR70523 25-4317 255112 UD808821(DENSO)S 63721489010 WOOSTR70522 LRS2644 120.566.092.050 9514 88214333 000986027020 DENDSN1398 CS1489 6040413.1 428080-4140 CGB-54317 255112D 428000-3460 LRS02644 MQS1489 120.566.092.415 MAV424130 115598 DV4DA 30484R J5214062 STR6271 31200-PWA-G52Add Your Number
