Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 219 mm |
Mount Hole Center - Center (O.1) | 94 mm |
Mount Hole Diameter (C.1) | 10 mm |
Mount Hole Diameter (C.2) | 10 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 15 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Insignia 2.0 4x4 Grand Sport | [B20NFT] | 03.2017- |
OPEL | Insignia 2.0 4x4 Grand Sport | [D20NFT] | 03.2017- |
OPEL | Insignia 2.0 4x4 Sports Tourer | [B20NFT] | 03.2017- |
OPEL | Insignia 2.0 4x4 Sports Tourer | [D20NFT] | 03.2017- |
Reference Information
CST40586GS 9855 88215199 12642699 95525318 UD819293(DENSO)S 10700N DSN1494 MAV425860 830.941.152.050 830.941.152.261 LRS04178 CST40586AS 256105D 20432685OE 6040586.1 LRS4178 438000-2410 12663052 25-5341 260540-0130Add Your Number
