Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 355 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 12.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 34 mm |
Rotation | CW |
Spigot Diameter (A) | 88 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO PENTA | Engine 5.1 | [MDE5] | 01.2015- |
VOLVO PENTA | Engine 7.7 | [MDE8] | 01.2015- |
Reference Information
M009T67879 21612056 20437886OE STM1748 MS1043 811.532.123.370 256270M M9T67879AM CST35688GS M009T67879AM 6035688.1 72524891 M9T67879 IS9525 UD100850(MITSUBISHI)S 11.139.227 AZE4715 MITM9T67879Add Your Number
