Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 306 mm |
Mount Hole Center - Center (O.1) | 175 mm |
Mount Hole Diameter (C.1) | 15 mm |
Mount Hole Diameter (C.2) | 15.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 56 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HITACHI | ZX470LC-6 | ||
ISUZU | Engine | [6UZ1X] | |
JOHN DEERE | 470G LC | ||
SUMITOMO | SH460 |
Reference Information
M009T62372 STRE084 M009T62371 255759M M9T61871 UD14734(MITSUBISHI)S 20437356BN CST35653GS 1811004322 130-90122N 1811004320 STR5375 6035653 20437356OE MAV376530A 255759 M009T61871 STM5625 8982222030 8982222033 CST35653AS M9T62371 M9T62372 6035653.1 STR71303 M009T62372AM 1811004250 M9T62372AM 131.520.112.130 131.520.112.370 WOOSTR71303Add Your Number
