Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 208 mm |
Mount Hole Center - Center (O.1) | 88 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 9 mm |
Rotation | ACW |
Spigot Diameter (A) | 62 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MOTO GUZZI | V35 | 01.1977-12.1979 | |
MOTO GUZZI | V65 | 01.1982-12.1987 | |
MOTO GUZZI | V75 | 01.1986-12.1987 |
Reference Information
432599 6015174.1 307307110 VAL432599 UD809004(VALEO)S STV3974 D6RA21 18355N 254030 400.501.092.500 113974 88214480 332003 PRSL874 RS41339 400.501.092.000 20479471OE 30730710 S12VA0454A2 190237 25-3043 3955 MAV171740 254030V LRS1550 71-20-18355 CGB-53043 30730711 CST15174GS STR00094 11877 PRSL874V LRS01550 400.501.092.008 STRL874 STR50069 STRL874V D6RA210Add Your Number
