Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 287 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M12x1.75 mm |
| Mount Hole Diameter (C.2) | M12x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 20 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 C4 2.5 TDi | [AAT] | 06.1994-10.1997 |
| AUDI | A6 C4 2.5 TDi | [AAT] | 06.1994-12.1997 |
| VOLVO | 940 2.4 | [D24T] | 08.1990-07.1994 |
| VOLVO | 940 2.4 D | [D24] | 08.1990-07.1995 |
| VOLVO | 940 2.4 D | [D24] | 08.1990-12.1994 |
| VOLVO | 940 2.4 TD | [D24T] | 08.1990-12.1994 |
| VOLVO | 940 2.4 TD | [D24TIC] | 08.1990-08.1994 |
| VOLVO | 940 2.4 TD | [D24TIC] | 08.1990-12.1994 |
| VOLVO | 940 2.4 TD | [D24TIC] | 08.1994-10.1998 |
| VOLVO | 960 2.4 TD | [D24TIC] | 09.1991-07.1994 |
| VOLVO | 960 2.4 TDi | [D24TIC] | 09.1990-08.1993 |
| VOLVO | V40 1.6 D2 | [D4162T] | 09.2013-12.2015 |
| VOLVO | V40 D2 | [D4162T] | 03.2012-12.2016 |
Reference Information
0001362070 1362070 S23-756 111112 000986011090 000986011091 069911023V 069911023AX CS347 UD101800S 1516743R 1257938 5001867 3411 1362077 69911023A 1362078 0001362069 1362083 0001362083 810.004.092.016 69911023 986011091 986011090 11118 STB0347 069911023A 0001362078 0001362077 69911023AX 1257325 1362069 436038Add Your Number
