Specifications
| Amp | 220 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Grooves | 8 qty |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56.5 mm |
| Outside Diameter (O.D.1) | 60.5 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 43 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F 350 6.7 | 01.2018- |
Reference Information
ALN3998 HC3Z-10346-G 104211-0910 HC3T-10300-GA 90-29-5960 290-10512 UD101773AAdd Your Number
