Specifications
| Amp | 50 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M12x1.25 mm |
| Diameter (D.2) | 12.5 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 12 qty |
| Length (L.1) | 214 mm |
| Mount Inside Length or Pad Mount C-C (C) | 80.5 mm |
| Outside Diameter (O.D.1) | 80 mm |
| Plug Code | PL_2003 |
| Product Line | Premium Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 38 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | 320C | ||
| CATERPILLAR | 320C-FM | ||
| CATERPILLAR | 320C-L | ||
| CATERPILLAR | 320D | ||
| CATERPILLAR | 320D-FM | ||
| CATERPILLAR | 320D-FMRR | ||
| CATERPILLAR | 320D-GC | ||
| CATERPILLAR | 320D-L | ||
| CATERPILLAR | 320D-LN | ||
| CATERPILLAR | 320D-LRR | ||
| CATERPILLAR | 320D-RR | ||
| CATERPILLAR | 321C | ||
| CATERPILLAR | 321D-LCR | ||
| CATERPILLAR | 323D | ||
| CATERPILLAR | 323D-L | ||
| CATERPILLAR | 323D-LN | ||
| CATERPILLAR | 323D-S | ||
| CATERPILLAR | 323D-SA |
Reference Information
212-8561 90-27-3280 A004TUF099 646.034.050.130 CAL35622GS 34368-03800 A004TU3599 CAL35622AS A4TUF099 A004TU3599AM 646.034.050.370 A24MH0146A2 2035622 A4TU3599ZC 20035622AV 230-40121 2565 20111N A4TUF099AM A4TU3599 ALT5151 20137226BN 5I7982 554381RIM 554381RI 446073 UD14728(MITSUBISHI)A A004TUF099AM 2035622.1 A4TU3599AM 116164 A004TU3599ZC ALM9935 10R7561 WOOALT31252Add Your Number
