Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 56 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Grooves | 8 qty |
| Length (L.1) | 192 mm |
| Outside Diameter (O.D.1) | 61.5 mm |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 86.5 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 344K | ||
| JOHN DEERE | 344L | ||
| JOHN DEERE | 5075M | ||
| JOHN DEERE | 5085E | ||
| JOHN DEERE | 5085M | ||
| JOHN DEERE | 5090EL | ||
| JOHN DEERE | 5090M | ||
| JOHN DEERE | 5100E | ||
| JOHN DEERE | 5100M | ||
| JOHN DEERE | 5100MH | ||
| JOHN DEERE | 5115M | ||
| JOHN DEERE | 5115ML | ||
| JOHN DEERE | 5125ML | ||
| JOHN DEERE | 6100ML | ||
| JOHN DEERE | 6105D | ||
| JOHN DEERE | 6105E | ||
| JOHN DEERE | 6120E | ||
| JOHN DEERE | 6135E | ||
| JOHN DEERE | 9420RX |
Reference Information
F00E100639 UD101942A 21104N 635.539.090.010 220-30298 CAL10A53GS 124325249 220-30298NOE 114317 124325207 0F00E100639 RE537507 DRA1158 2010135AOE 20010A53OV 2010A53.1 0124325249 0124325207Add Your Number
